Product Detailed Parameters
- Description：CMC 2.7MH 1.3A 2LN TH
- Series：ALFT-03A
- Mfr：Abracon LLC
- Package：Bulk
- Filter Type：Power Line
- Number of Lines：2
- Current Rating (Max)：1.3A
- DC Resistance (DCR) (Max)：680mOhm
- Voltage Rating - DC：250V
- Voltage Rating - AC：-
- Operating Temperature：-25°C ~ 85°C
- Ratings：-
- Approval Agency：-
- Features：-
- Mounting Type：Through Hole
- Size / Dimension：0.941" L x 0.709" W (23.90mm x 18.00mm)
- Height (Max)：0.850" (21.60mm)
- Package / Case：Vertical, 4 PC Pin
- Inductance @ Frequency：2.7 mH @ 1 kHz
- Impedance @ Frequency：-
- Qualification：-
- Grade：-
Download product information
Overview
The ALFT-03A-10 is a common mode filter choke from the Abracon ALFT series, designed for PCB mounting via radial through-hole termination. It features a vertical package with four PC pins and measures 23.9 mm in length, 18.00 mm in width, and 21.60 mm in maximum height. The component provides an inductance of 2.7 mH at 1 kHz and supports a maximum DC current of 1.3 A. Its maximum DC resistance is specified at 680 mOhm. The device operates within a temperature range of -25°C to +85°C.
Feature Summary
- Provides common mode noise suppression for AC line applications
- Vertical through-hole construction for secure PCB integration
- Radial pin configuration simplifies automated assembly
Applications
- AC power input filtering
- EMI suppression in consumer electronics
- Power supply noise reduction
Procurement Notes
Verify the specific part number suffix against official Abracon documentation to confirm electrical characteristics such as inductance and current rating. Ensure the selected variant matches the required thermal operating range and physical dimensions for the target PCB layout. Cross-reference datasheet parameters with design specifications before finalizing procurement orders.
Selection Notes
Select this component based on its 2.7 mH inductance and 1.3 A current handling capability. Verify that the 680 mOhm DC resistance aligns with system efficiency requirements. Confirm the vertical package dimensions fit the available board space and that the through-hole pitch matches the PCB footprint design.
Part Context
This component belongs to the ALFT series of common mode chokes manufactured by Abracon LLC. The series offers various inductance and current ratings tailored for different power line filtering needs. The ALFT-03A-10 specifically targets applications requiring moderate inductance with higher current capacity compared to lower-rated variants in the same form factor.
Replacement Considerations
Consult official Abracon documentation for verified substitute part numbers within the ALFT series or equivalent products from other manufacturers. Ensure any replacement maintains identical inductance, current rating, and physical dimensions to guarantee compatibility.
