AM1350B514

Overview

The AM1350B514 is a ceramic band pass filter manufactured by Anatech Electronics Inc. It operates with a center frequency of 1350 MHz and features a bandwidth of 40 MHz. The component is designed for a system impedance of 50 Ohms. It is housed in a 14-SMD module package, measuring 0.512 inches in length and 0.413 inches in width (13.00mm x 10.50mm), with a maximum height of 0.157 inches (4.00mm). The device complies with RoHS3 standards.

Feature Summary

• Utilizes ceramic technology for stable RF filtering performance
• Designed as a band pass filter with specific center frequency characteristics
• Constructed in a compact surface mount module format

Applications

• RF signal processing systems requiring 1350 MHz band selection
• Microwave communication equipment interfaces
• Test and measurement instrumentation filters

Procurement Notes

Verify the exact datasheet version and RoHS3 compliance status directly with Anatech Electronics Inc. or authorized distributors before procurement. Confirm that the 14-SMD package dimensions align with your PCB footprint requirements. Ensure the 50 Ohm impedance matches your circuit design specifications to prevent signal reflection issues.

Selection Notes

Select this component when a fixed 1350 MHz center frequency with 40 MHz bandwidth is required. The 50 Ohm impedance rating must match the source and load impedances in the application. Consider the physical size constraints of the 14-SMD module during layout planning. Verify thermal management needs as ceramic filters may dissipate power differently than other types.

Part Context

Anatech Electronics Inc. specializes in RF and microwave filters, including ceramic and cavity designs. The AM1350B514 belongs to their line of ceramic band pass filters, which are engineered for high stability and precise frequency response in demanding RF environments. This part represents their standard offering for mid-frequency microwave applications.

Replacement Considerations

No public substitute part numbers are confirmed for this specific model. Cross-referencing requires matching the 1350 MHz center frequency, 40 MHz bandwidth, 50 Ohm impedance, and 14-SMD package dimensions exactly.
