AM1D-0303DH60Z

AM1D-0303DH60Z is listed in the DC DC Converters range at ChipApex. The manufacturer field lists aimtec. Its product description is DC DC CONVERTER +/-3.3V 1W. Review the specifications below when checking this part for your BOM.

DC DC Converters specifications for AM1D-0303DH60Z

• Description：DC DC CONVERTER +/-3.3V 1W
• Series：AM1D-Z (1W)
• Mfr：aimtec
• Package：Tube
• Type：Isolated Module
• Number of Outputs：2
• Voltage - Input (Min)：2.97V
• Voltage - Input (Max)：3.63V
• Voltage - Output 1：3.3V
• Voltage - Output 2：-3.3V
• Voltage - Output 3：-
• Voltage - Output 4：-
• Current - Output (Max)：152mA, 152mA
• Power (Watts)：1 W
• Voltage - Isolation：6 kV
• Applications：ITE (Commercial)
• Features：-
• Operating Temperature：-40°C ~ 85°C
• Efficiency：66%
• Mounting Type：Through Hole
• Package / Case：7-SIP Module
• Size / Dimension：0.76" L x 0.24" W x 0.39" H (19.5mm x 6.0mm x 10.0mm)
• Supplier Device Package：-
• Control Features：-
• Approval Agency：CE, cULus, cURus
• Standard Number：-
• Grade：-
• Qualification：-
