AM6526BACDXEAF

Overview

The AM6526BACDXEAF is a Sitara processor featuring dual Arm Cortex-A53 cores and dual Arm Cortex-R5F cores. It includes a PowerVR SGX544-MP1 GPU, three PRU_ICSSG subsystems, and supports DDR4 memory up to 8GB. The device utilizes a 784-pin FCBGA package with 242 I/O pins.

Feature Summary

• Dual-core Arm Cortex-A53 microprocessor subsystem
• Three gigabit Industrial Communication Subsystems (PRU_ICSSG)
• Functional safety compliance for industrial applications
• Integrated cryptographic acceleration and secure boot

Applications

• Industrial Programmable Logic Controllers (PLC)
• Factory automation with safety functions
• Multi-protocol fieldbus communications
• Industrial PC
• Human Machine Interface (HMI)

Procurement Notes

Verify the specific silicon revision and ordering suffix against official documentation to ensure compatibility with required functional safety certifications and software support packages.

Selection Notes

Select this model for designs requiring dual A53 processing power combined with deterministic industrial Ethernet capabilities via PRU_ICSSG. Ensure the application does not require the quad-core configuration or GPU features found in other family members.

Part Context

This component belongs to the Texas Instruments AM652x Sitara processor family, designed for modern Industry 4.0 embedded products. It shares architectural similarities with the AM654x series but offers a reduced core count and lacks certain multimedia accelerators.

Replacement Considerations

AM6528BACDXEA

FAQ

Does the AM6526 support lockstep mode?

Yes, the dual-core Arm Cortex-R5F subsystem supports lockstep mode.

What type of memory does the DDRSS support?

The DDR Subsystem supports DDR4 memory types up to DDR-1600.
