Product Detailed Parameters
- Description：CMC 2LN THROUGH HOLE INDUSTRIAL
- Series：AMFW24-NZ
- Mfr：aimtec
- Package：Box
- Filter Type：Power Line
- Number of Lines：2
- Current Rating (Max)：-
- DC Resistance (DCR) (Max)：-
- Voltage Rating - DC：10V
- Voltage Rating - AC：-
- Operating Temperature：-40°C ~ 85°C
- Ratings：-
- Approval Agency：-
- Features：Industrial
- Mounting Type：Through Hole
- Size / Dimension：-
- Height (Max)：0.748" (19.00mm)
- Package / Case：-
- Inductance @ Frequency：-
- Impedance @ Frequency：-
- Qualification：-
- Grade：-
Download product information
Overview
The AMFW24-1.25NZ is a two-line common mode choke designed for industrial power line applications. It features through-hole mounting and provides electromagnetic interference suppression. The component is constructed for durability in demanding environments, meeting industrial standards. It serves as a critical accessory for power supply converters to ensure signal integrity and compliance with emission regulations.
Feature Summary
- Two-line common mode choke configuration for effective noise suppression
- Through-hole mounting design suitable for PCB integration
- Industrial-grade construction for robust performance
Applications
- Power line filtering for industrial equipment
- Electromagnetic interference suppression in power supply circuits
- Accessory for Aimtec DC/DC converters
Procurement Notes
Verify the specific suffix requirements when ordering, as variants such as AMFW24-1.25NZ-ST exist. Confirm that the through-hole package type matches your board layout. Ensure the industrial classification aligns with your system's environmental specifications before finalizing procurement.
Selection Notes
Select this component when industrial-grade EMI filtering is required for two-line power inputs. Consider the through-hole mounting constraint during PCB design. Verify compatibility with the associated power supply converter model to ensure proper noise attenuation characteristics are met.
Part Context
This part belongs to the Aimtec power supply accessories category, specifically within the EMC filter and common mode choke subgroups. It complements Aimtec's DC/DC converter portfolio by providing necessary input/output filtering solutions for maintaining regulatory compliance and operational stability in noisy industrial settings.
Replacement Considerations
Publicly confirmed substitute part numbers are not available in the provided documentation. Users should consult official Aimtec resources or distributor databases for equivalent components if direct replacement is necessary.
