Product Detailed Parameters
- Description：CMC 2LN DIN RAIL INDUSTRIAL
- Series：AMFW24-JZ
- Mfr：aimtec
- Package：Box
- Filter Type：Power Line
- Number of Lines：2
- Current Rating (Max)：-
- DC Resistance (DCR) (Max)：-
- Voltage Rating - DC：9V
- Voltage Rating - AC：-
- Operating Temperature：-40°C ~ 85°C
- Ratings：-
- Approval Agency：-
- Features：Industrial
- Mounting Type：DIN Rail
- Size / Dimension：-
- Height (Max)：1.122" (28.50mm)
- Package / Case：-
- Inductance @ Frequency：-
- Impedance @ Frequency：-
- Qualification：-
- Grade：-
Download product information
Overview
The Aimtec AMFW24-1JZ-STD is a common mode choke (CMC) designed for industrial DIN rail mounting. It functions as an EMC filter and surge suppressor for DC power lines. The device supports an input voltage range of 9 to 36 VDC with a maximum current rating of 1.0 A. It provides isolation of 1500 VAC and operates within a temperature range of -40°C to +85°C. Surge suppression capabilities include 2 kV between line-to-neutral and 4 kV between line-to-ground. The unit meets EMI requirements per EN55032 Class B standards.
Feature Summary
- Provides electromagnetic compatibility filtering for noise-sensitive applications
- Offers high-voltage isolation for safety in industrial environments
- Surge suppression capability protects downstream equipment from voltage spikes
Applications
- Industrial DIN rail mounted power systems
- Noise-sensitive electronic equipment requiring EMC compliance
- DC power line protection against common mode interference
Procurement Notes
Verify the specific part number suffix to ensure correct configuration, as variations may exist within the series. Confirm that the required surge suppression ratings and isolation voltage meet your system's safety standards. Check for any updated datasheets or regulatory certifications relevant to your region before finalizing procurement decisions.
Selection Notes
Select this component when DIN rail mounting is required for DC power line filtering. Ensure the operating voltage does not exceed 36 VDC and the current load remains within the 1.0 A limit. Consider the thermal environment to guarantee operation within the specified -40°C to +85°C range. Verify that EN55032 Class B compliance satisfies your application's EMI regulations.
Part Context
This component belongs to the Aimtec AMFW-JZ series of EMC filters. These devices are engineered specifically for industrial applications where robust noise suppression and safety isolation are critical. The series utilizes passive components to attenuate common mode noise without active circuitry, ensuring reliability in harsh electrical environments.
Replacement Considerations
Publicly confirmed substitute part numbers for this specific model were not identified in available documentation. Users should consult official Aimtec resources or authorized distributors for verified cross-reference information before substituting this component.
