AMFW40-3JZ-STD-B

$25.20

Description：CMC 2LN DIN RAIL INDUSTRIAL
Series：AMFW40-JZ
Mfr：aimtec
Package：Box

SKU:2e4de408ac3f Category: Common Mode Chokes Brand: aimtec

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：CMC 2LN DIN RAIL INDUSTRIAL
Series：AMFW40-JZ
Mfr：aimtec
Package：Box
Filter Type：Power Line
Number of Lines：2
Current Rating (Max)：-
DC Resistance (DCR) (Max)：-
Voltage Rating - DC：-
Voltage Rating - AC：-
Operating Temperature：-40°C ~ 85°C
Ratings：-
Approval Agency：-
Features：Industrial
Mounting Type：DIN Rail
Size / Dimension：-
Height (Max)：1.024" (26.00mm)
Package / Case：-
Inductance @ Frequency：-
Impedance @ Frequency：-
Qualification：-
Grade：-

Download product information

AMFW40-3JZ-STD-B

Overview

The AMFW40-3JZ-STD-B is a common mode choke (CMC) designed for industrial DIN rail mounting. It features 17 lines and operates within a temperature range of -40°C to +85°C. The component supports an input voltage of 0 to 80 VDC with a maximum current of 3.0A. It provides isolation of 1500VDC and meets EMI standards EN55032 Class B, offering attenuation of 20dB from 150kHz to 100MHz.

Feature Summary

Industrial-grade EMC filtering for DC power lines
DIN rail mounting configuration for panel integration
High isolation voltage rating for safety compliance
Passive EMI suppression meeting Class B standards

Applications

Industrial control systems requiring EMI suppression
DC power distribution panels
Equipment complying with EN55032 Class B limits
Rail-mounted electrical enclosures

Procurement Notes

Verify the specific suffix 'B' against the manufacturer's latest documentation to confirm exact pinout and mechanical dimensions. Ensure the required line count matches the 17-line specification. Confirm that the 80VDC voltage rating and 3.0A current capacity align with the system design requirements before procurement.

Selection Notes

Select this component when DIN rail mounting is required for high-density installations. It is suitable for applications needing significant common mode noise reduction in DC circuits. Consider the physical height of 26.00mm for enclosure space planning. Verify compatibility with terminal block termination methods used in the target assembly.

Part Context

This part belongs to the Aimtec AMFW40-JZ series of passive EMC filters. These components are engineered for robust performance in harsh industrial environments. The series typically offers various line configurations to suit different power distribution needs while maintaining compact form factors for DIN rail integration.

Replacement Considerations

Check Aimtec datasheets for alternative suffixes or models within the AMFW40-JZ series that may offer different line counts or voltage ratings. Ensure any substitute maintains the same DIN rail mounting style and terminal block termination type to fit existing infrastructure.
