Product Detailed Parameters
- Description：CMC 2LN THROUGH HOLE INDUSTRIAL
- Series：AMFW48-JZ
- Mfr：aimtec
- Package：Box
- Filter Type：Power Line
- Number of Lines：2
- Current Rating (Max)：-
- DC Resistance (DCR) (Max)：-
- Voltage Rating - DC：18V
- Voltage Rating - AC：-
- Operating Temperature：-40°C ~ 85°C
- Ratings：-
- Approval Agency：-
- Features：Industrial
- Mounting Type：Through Hole
- Size / Dimension：-
- Height (Max)：0.591" (15.00mm)
- Package / Case：-
- Inductance @ Frequency：-
- Impedance @ Frequency：-
- Qualification：-
- Grade：-
Download product information
Overview
The Aimtec AMFW48-1JZ is a common mode choke designed for industrial EMC filtering applications. It operates within a wide input voltage range of 18 to 75 Vdc and supports power levels up to 100W. The component functions effectively across a frequency screening range of 0.15MHz to 100MHz. It utilizes chassis mounting with terminal block termination, ensuring robust integration into industrial power systems requiring reliable noise suppression.
Feature Summary
- Industrial-grade EMC filtering capability
- Wide DC input voltage compatibility
- Chassis mount construction
Applications
- Industrial power supply noise suppression
- DC/DC converter input/output filtering
- AC/DC converter EMI reduction
Procurement Notes
Verify the specific suffix (e.g., -ST, -STD) against your design requirements, as these may indicate variations in mounting hardware or packaging. Confirm that the terminal block termination aligns with your PCB or wire harness interface. Ensure the chassis mounting style fits your enclosure constraints. Cross-reference the datasheet for exact physical dimensions and torque specifications before finalizing procurement.
Selection Notes
Select this component when industrial environmental ratings are required for DC power lines. The wide voltage range accommodates various bus architectures from 18V to 75V. Consider the chassis mount form factor if panel installation is preferred over PCB footprint limitations. Verify that the 100MHz screening level meets your specific electromagnetic interference mitigation standards.
Part Context
This part belongs to the Aimtec AMFW48-JZ series, which provides EMC line filtering solutions. The series covers output powers up to 100W and is designed for industrial screening levels. It complements Aimtec's modular AC/DC and DC/DC converters by providing necessary front-end or back-end noise filtration for stable operation in electrically noisy environments.
Replacement Considerations
Check Aimtec datasheets for other models in the AMFW48-JZ series, such as AMFW48-1JZ-ST-B, for potential substitutes. Verify that any replacement maintains the same voltage rating, current capacity, and mounting style. Ensure the alternative part meets the same industrial screening requirements.
