AMI-27-16-3

Power Line Filter Modules Overview

The AMI-27-16-3 is a single-phase EMC/EMI line filter module manufactured by Altran Magnetics, LLC. It features a two-stage filtering design rated for 16 A current and operates within a voltage range of 110 to 250 VAC at frequencies up to 400 Hz. The unit utilizes a chassis mount style for secure installation. This component is designed to suppress electromagnetic interference in power lines, ensuring compliance with emission standards while maintaining signal integrity in sensitive electronic applications.

Power Line Filter Modules Feature Summary

• Two-stage filtering architecture for enhanced noise suppression
• Chassis mount configuration for robust mechanical stability
• Single-phase design optimized for standard AC power lines

Power Line Filter Modules Applications

• Industrial power supply systems requiring EMI reduction
• Medical equipment power input stages
• Precision measurement instrumentation protection

Power Line Filter Modules Procurement Notes

Verify the specific datasheet version and RoHS compliance status directly with Altran Magnetics or authorized distributors before procurement. Confirm that the chassis mounting requirements align with your enclosure specifications. Ensure the operating frequency range up to 400 Hz meets your system's electrical environment needs.

Power Line Filter Modules Selection Notes

Select this model when a compact, single-phase solution is required for suppressing conducted emissions in 110-250 VAC circuits. The 16 A rating suits moderate power applications. Consider the chassis mount form factor if panel integration is preferred over PCB mounting. Validate thermal performance under continuous load conditions.

Power Line Filter Modules Part Context

This component belongs to the AMI series of line filter modules from Altran Magnetics. These filters are engineered for general-purpose electromagnetic compatibility improvement in AC power inputs. The series offers various current ratings and configurations to suit different industrial and commercial power distribution requirements.

Power Line Filter Modules Replacement Considerations

No public confirmed substitute part numbers are available in the provided documentation. Consult Altran Magnetics technical support for equivalent alternatives if this specific model is unavailable.

Power Line Filter Modules FAQ

What is the maximum operating frequency for the AMI-27-16-3?

The filter is rated for operation at frequencies up to 400 Hz.

Does the AMI-27-16-3 use a PCB or chassis mount?

It utilizes a chassis mount style for installation.
