AMI-M11J-6-10-B

Power Line Filter Modules Overview

The AMI-M11J-6-10-B is a single-phase EMC/EMI line filter manufactured by Altran Magnetics, LLC. It features a rated current of 6 A and supports AC voltages up to 250 V at 50/60 Hz. The unit utilizes a single-stage filtering configuration with threaded post termination (8-32). Designed for chassis mounting, it operates within a temperature range of -10°C to +40°C.

Power Line Filter Modules Feature Summary

• Single-stage electromagnetic interference suppression
• Threaded post terminal connection
• Chassis mount installation style

Power Line Filter Modules Applications

• Industrial equipment power input filtering
• Commercial machinery EMI reduction
• General purpose AC power line noise suppression

Power Line Filter Modules Procurement Notes

Verify the specific suffix codes against official Altran Magnetics documentation to confirm exact electrical ratings and termination styles. Ensure the operating environment remains within the specified -10°C to +40°C range. Confirm chassis mounting compatibility before integration into the final assembly design.

Power Line Filter Modules Selection Notes

Select this component when a single-stage solution is sufficient for the application's noise profile. The 6 A rating must accommodate peak load currents without exceeding thermal limits. Verify that the 8-32 threaded post terminals align with the system's busbar or wiring infrastructure requirements.

Power Line Filter Modules Part Context

This part belongs to the AMI-M11J series of power line filters from Altran Magnetics. The series offers various current ratings and voltage configurations for single-phase applications. This specific model provides a compact solution for moderate current requirements in industrial and commercial environments.

Power Line Filter Modules FAQ

What is the maximum operating temperature?

The maximum operating temperature is +40°C.

What type of termination does this filter use?

It uses 8-32 threaded post terminals.
