AML04B13-2R3M6R5-S1

$1.48

Description：CMC 6.5A 2LN TH AEC-Q200
Series：AML
Mfr：TDK Corporation
Package：Tray

SKU:3f82a291c1bf Category: Common Mode Chokes Brand: TDK Corporation

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：CMC 6.5A 2LN TH AEC-Q200
Series：AML
Mfr：TDK Corporation
Package：Tray
Filter Type：Power Line
Number of Lines：2
Current Rating (Max)：6.5A
DC Resistance (DCR) (Max)：15mOhm
Voltage Rating - DC：-
Voltage Rating - AC：-
Operating Temperature：-40°C ~ 125°C
Ratings：AEC-Q200
Approval Agency：-
Features：-
Mounting Type：Through Hole
Size / Dimension：0.177" Dia x 0.512" L (4.50mm x 13.00mm)
Height (Max)：-
Package / Case：Radial, Horizontal Cylinder
Inductance @ Frequency：-
Impedance @ Frequency：-
Qualification：-
Grade：-

Download product information

AML04B13-2R3M6R5-S1

Overview

The AML04B13-2R3M6R5-S1 is a common mode choke coil from TDK Corporation's AML series, designed for through-hole mounting. It features an inductance of 2.3 µH with a tolerance of 20%. The component supports a maximum DC current of 6.5 A and exhibits a maximum DC resistance of 15 mΩ. It operates within a temperature range of -40°C to +125°C. The device has a diameter of 4 mm and a lead spacing of 9.2 mm. It is certified under the AEC-Q200 standard for automotive applications.

Feature Summary

Provides common mode noise suppression for two-line circuits
Complies with AEC-Q200 qualification standards for automotive reliability
Utilizes a shielded core structure to minimize electromagnetic interference

Applications

Automotive electronic control units
Power supply input filtering
Data line noise suppression

Procurement Notes

Verify the specific suffix S1 against the official TDK datasheet to confirm package and termination details. Ensure the AEC-Q200 certification requirement matches the target application environment. Cross-reference the manufacturer part number with authorized distributors to avoid counterfeit components. Confirm that the 6.5A rated current meets the circuit's peak load requirements without saturation.

Selection Notes

Select this component when a 2.3 µH inductance value is required for common mode noise reduction in automotive or industrial settings. The 6.5A current rating suits moderate power applications. Consider the through-hole form factor if PCB layout constraints favor axial or radial leaded components over surface mount alternatives. Verify thermal management capabilities given the 15 mΩ DC resistance at high currents.

Part Context

This component belongs to TDK's AML series of common mode chokes, which are engineered for robust performance in noisy environments. The series offers various inductance values and current ratings to suit different filtering needs. The AML04B13 variant specifically targets applications requiring compact sizing with high current handling capabilities while maintaining low insertion loss.

Replacement Considerations

Check TDK's official substitution list for equivalent parts with similar inductance and current ratings. Verify pin compatibility and mechanical dimensions before replacing. Ensure any substitute also holds AEC-Q200 certification if used in automotive contexts.
