AML0620-5R9M6R8-S1

$1.74

Description：CMC 6.8A 2LN TH AEC-Q200
Series：AML
Mfr：TDK Corporation
Package：Tray

SKU:54cb0856ebe1 Category: Common Mode Chokes Brand: TDK Corporation

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：CMC 6.8A 2LN TH AEC-Q200
Series：AML
Mfr：TDK Corporation
Package：Tray
Filter Type：Power Line
Number of Lines：2
Current Rating (Max)：6.8A
DC Resistance (DCR) (Max)：16mOhm
Voltage Rating - DC：-
Voltage Rating - AC：-
Operating Temperature：-40°C ~ 125°C
Ratings：AEC-Q200
Approval Agency：-
Features：-
Mounting Type：Through Hole
Size / Dimension：0.236" Dia x 0.787" L (6.00mm x 20.00mm)
Height (Max)：-
Package / Case：Radial, Horizontal Cylinder
Inductance @ Frequency：-
Impedance @ Frequency：-
Qualification：-
Grade：-

Download product information

AML0620-5R9M6R8-S1

Overview

The AML0620-5R9M6R8-S1 is a through-hole common mode choke manufactured by TDK Corporation. It features a radial horizontal package and is rated for 6.8A current with an inductance of 5.9µH ±20%. The component exhibits a maximum DC resistance of 16mΩ and complies with the AEC-Q200 automotive qualification standard. It operates within a temperature range of -40°C to +125°C, providing electromagnetic interference suppression for power lines and signal transmission applications.

Feature Summary

Suppresses common mode noise in power lines and signal transmission circuits
Complies with AEC-Q200 automotive electronic component qualification standards
Designed for high current handling up to 6.8A with low impedance characteristics

Applications

Automotive electronics systems requiring AEC-Q200 compliance
Power supply input filtering for industrial equipment
Signal line noise suppression in data processing units

Procurement Notes

Verify the specific datasheet version provided by the supplier to confirm exact mechanical dimensions and soldering guidelines. Ensure the ordering suffix matches the required packaging configuration. Cross-reference the AEC-Q200 certification status directly with TDK documentation to validate automotive suitability for the intended application environment.

Selection Notes

Select this component when automotive reliability standards are mandatory for the design. The 6.8A rating suits high-current power paths, while the 5.9µH inductance targets specific frequency noise profiles. Verify that the radial horizontal package fits the PCB layout constraints and that the operating temperature range covers the system's thermal extremes.

Part Context

This part belongs to the AML series of common mode chokes from TDK Corporation. The series is characterized by its robust construction suitable for demanding environments. The AML0620 variant specifically addresses the need for high-current filtering in compact through-hole layouts, bridging general industrial requirements with strict automotive quality benchmarks.
