Product Detailed Parameters
- Description：CMC 11A 2LN TH AEC-Q200
- Series：AML
- Mfr：TDK Corporation
- Package：Tray
- Filter Type：Power Line
- Number of Lines：2
- Current Rating (Max)：11A
- DC Resistance (DCR) (Max)：13mOhm
- Voltage Rating - DC：-
- Voltage Rating - AC：-
- Operating Temperature：-40°C ~ 125°C
- Ratings：AEC-Q200
- Approval Agency：-
- Features：-
- Mounting Type：Through Hole
- Size / Dimension：0.335" Dia x 0.984" L (8.50mm x 25.00mm)
- Height (Max)：-
- Package / Case：Radial, Horizontal Cylinder
- Inductance @ Frequency：-
- Impedance @ Frequency：-
- Qualification：-
- Grade：-
Download product information
Overview
The TDK AML0925-8R0M110-S1 is a through-hole common mode choke coil designed for power line noise suppression. It features a radial horizontal cylinder package with dimensions of 8.50mm diameter by 25.00mm length. The component supports a maximum rated current of 11A and a saturation current of 8.0A. Key electrical parameters include a DC resistance (DCR) of 13mΩ, an inductance of 8µH ±20%, and an operating temperature range of -40°C to +125°C. It holds AEC-Q200 automotive qualification.
Feature Summary
- Utilizes high saturation flux density ferrite cores for compact design
- Terminal structure suitable for motor drive digital equipment installation
- Complies with automotive quality standards via AEC-Q200 certification
- Provides effective wide-band noise elimination with excellent high-frequency characteristics
Applications
- Motor drive circuits
- Automotive electronic systems
- Power line noise suppression
Procurement Notes
Verify the specific suffix S1 against official TDK documentation to confirm exact pin configuration and packaging details. Ensure the procurement channel provides valid traceability for AEC-Q200 certified components intended for automotive applications. Cross-reference the manufacturer part number with authorized distributor lists to avoid counterfeit products.
Selection Notes
Select this component when designing circuits requiring robust common mode noise filtering for high-current power lines up to 11A. The 8µH inductance value is suitable for suppressing wide-band electromagnetic interference in automotive environments. Consider the radial through-hole mounting style if PCB layout constraints favor horizontal cylinder packages over surface mount alternatives.
Part Context
This component belongs to the TDK AML series of common mode chokes. The series is characterized by the use of proprietary ferrite materials to achieve high performance in small form factors. The AML series is specifically engineered to meet the rigorous reliability and environmental requirements of modern automotive electronics and industrial control systems.
Replacement Considerations
Consult TDK's official cross-reference guides for direct replacements within the AML series. Verify that any substitute maintains the same 11A current rating, 13mΩ DCR, and AEC-Q200 qualification status to ensure compatibility with existing automotive designs.
