AMPLH4020S-R15MT

$0.35

Description：IND 0.15UH 15A 3.8M
Series：AMPLH4020S
Mfr：Abracon LLC
Package：Tape & Reel (TR)

SKU:df52c9f3a0fc Category: Fixed Inductors Brand: Abracon LLC

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

AMPLH4020S-R15MT is listed in the Fixed Inductors range at ChipApex. The manufacturer field lists Abracon LLC. Its product description is IND 0.15UH 15A 3.8M. Review the specifications below when checking this part for your BOM.

Fixed Inductors specifications for AMPLH4020S-R15MT

Description：IND 0.15UH 15A 3.8M
Series：AMPLH4020S
Mfr：Abracon LLC
Package：Tape & Reel (TR)
Type：Molded
Material - Core：Alloy Powder
Inductance：150 nH
Tolerance：±20%
Current Rating (Amps)：16.5 A
Current - Saturation (Isat)：29A
Shielding：Shielded
DC Resistance (DCR)：3.8mOhm Max
Q @ Freq：-
Frequency - Self Resonant：-
Ratings：-
Operating Temperature：-40°C ~ 125°C
Inductance Frequency - Test：100 kHz
Mounting Type：Surface Mount
Package / Case：Nonstandard
Supplier Device Package：-
Size / Dimension：0.169" L x 0.165" W (4.30mm x 4.20mm)
Height - Seated (Max)：0.083" (2.10mm)
Features：-

Fixed Inductors datasheet and documents for AMPLH4020S-R15MT

AMPLH4020S-R15MT

Fixed Inductors Overview

The AMPLH4020S-R15MT is a shielded surface-mount power inductor from Abracon LLC, designed for high-current applications. It features an inductance of 150 nH with a tolerance of ±20%. The component supports a temperature rise current of 16.5 A and a saturation current of 29 A. Its maximum DC resistance is 3.8 mΩ. The device operates within a temperature range of -40°C to +125°C and utilizes carbonyl powder core material for reduced losses.

Fixed Inductors Feature Summary

Shielded molded construction utilizing metal alloy or carbonyl powder molding to minimize core losses and enhance efficiency.
High power density design optimized for commercial, transportation, medical, and industrial environments.
Low DC resistance characteristics supporting high-current performance in compact surface-mount form factors.

Fixed Inductors Applications

Commercial electronic systems requiring efficient power management
Transportation equipment power circuits
Medical device power supplies
Industrial application power stages

Fixed Inductors Procurement Notes

Verify the specific part number AMPLH4020S-R15MT against official Abracon documentation to confirm electrical parameters such as inductance and current ratings. Ensure compatibility with PCB footprint requirements and operating temperature ranges specified in the datasheet before integration into final designs.

Fixed Inductors Selection Notes

Select this component when high current handling and low DC resistance are critical for system efficiency. The shielded design prevents magnetic interference, making it suitable for dense layouts. Consider the saturation current rating relative to peak load conditions to ensure reliable operation under varying thermal environments.

Fixed Inductors Part Context

This component belongs to the AMPLH4020S series of high-power molded inductors. The series offers various inductance values within a standardized SMD package, providing designers with flexibility for different power conversion requirements while maintaining consistent physical dimensions and mounting characteristics across the product line.

Fixed Inductors Replacement Considerations

No public confirmed substitute part numbers are available in the provided documentation. Verify cross-reference options through official manufacturer channels if alternative sourcing is required.
