APAL00060645220M80 is listed in the Fixed Inductors range at ChipApex. The manufacturer field lists Pulse Electronics. Its product description is INDUCTOR POWER. Review the specifications below when checking this part for your BOM.
Fixed Inductors specifications for APAL00060645220M80
- Description：INDUCTOR POWER
- Series：APAL
- Mfr：Pulse Electronics
- Package：Tape & Reel (TR)
- Type：Drum Core, Wirewound
- Material - Core：Ferrite
- Inductance：22 µH
- Tolerance：±20%
- Current Rating (Amps)：1.8 A
- Current - Saturation (Isat)：1.4A
- Shielding：Shielded
- DC Resistance (DCR)：75mOhm
- Q @ Freq：-
- Frequency - Self Resonant：-
- Ratings：AEC-Q200
- Operating Temperature：-40°C ~ 125°C
- Inductance Frequency - Test：100 kHz
- Mounting Type：Surface Mount
- Package / Case：Nonstandard
- Supplier Device Package：-
- Size / Dimension：0.283" L x 0.236" W (7.20mm x 6.00mm)
- Height - Seated (Max)：0.189" (4.80mm)
- Features：-
Fixed Inductors datasheet and documents for APAL00060645220M80
