ASD05H-12D15

ASD05H-12D15 is listed in the DC DC Converters range at ChipApex. The manufacturer field lists Astrodyne TDI. Its product description is 5W Dual Output Isolated and Regu. Review the specifications below when checking this part for your BOM.

DC DC Converters specifications for ASD05H-12D15

• Description：5W Dual Output Isolated and Regu
• Series：ASD05H (5W)
• Mfr：Astrodyne TDI
• Package：Bulk
• Type：Isolated Module
• Number of Outputs：2
• Voltage - Input (Min)：9V
• Voltage - Input (Max)：36V
• Voltage - Output 1：15V
• Voltage - Output 2：-15V
• Voltage - Output 3：-
• Voltage - Output 4：-
• Current - Output (Max)：170mA, 170mA
• Power (Watts)：5.1 W
• Voltage - Isolation：500 V
• Applications：ITE (Commercial)
• Features：Remote On/Off
• Operating Temperature：-25°C ~ 71°C (With Derating)
• Efficiency：83%
• Mounting Type：Through Hole
• Package / Case：6-DIP Module
• Size / Dimension：2.00" L x 1.00" W x 0.41" H (50.8mm x 25.4mm x 10.5mm)
• Supplier Device Package：-
• Control Features：Enable, Active High
• Approval Agency：cURus
• Standard Number：60950-1
• Grade：-
• Qualification：-

DC DC Converters datasheet and documents for ASD05H-12D15
