ASD10H-48S5

ASD10H-48S5 is listed in the DC DC Converters range at ChipApex. The manufacturer field lists Astrodyne TDI. Its product description is Isolated and Regulated 10 WATT O. Review the specifications below when checking this part for your BOM.

DC DC Converters specifications for ASD10H-48S5

• Description：Isolated and Regulated 10 WATT O
• Series：ASD10H (10W)
• Mfr：Astrodyne TDI
• Package：Bulk
• Type：Isolated Module
• Number of Outputs：1
• Voltage - Input (Min)：18V
• Voltage - Input (Max)：75V
• Voltage - Output 1：5V
• Voltage - Output 2：-
• Voltage - Output 3：-
• Voltage - Output 4：-
• Current - Output (Max)：2A
• Power (Watts)：10 W
• Voltage - Isolation：1.5 kV
• Applications：ITE (Commercial)
• Features：Heat Sink
• Operating Temperature：-25°C ~ 71°C (With Derating)
• Efficiency：82%
• Mounting Type：Through Hole
• Package / Case：6-DIP Module
• Size / Dimension：2.00" L x 1.00" W x 0.41" H (50.8mm x 25.4mm x 10.5mm)
• Supplier Device Package：-
• Control Features：-
• Approval Agency：UL
• Standard Number：60950-1
• Grade：-
• Qualification：-

DC DC Converters datasheet and documents for ASD10H-48S5
