ASPI-0418FS-4R7M-T3

$0.26

Description：FIXED IND 4.7UH 1.7A 84 MOHM SMD
Series：ASPI-0418FS
Mfr：Abracon LLC
Package：Tape & Reel (TR),Cut Tape (CT)

SKU:269300446412 Category: Fixed Inductors Brand: Abracon LLC

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

ASPI-0418FS-4R7M-T3 is listed in the Fixed Inductors range at ChipApex. The manufacturer field lists Abracon LLC. Its product description is FIXED IND 4.7UH 1.7A 84 MOHM SMD. Review the specifications below when checking this part for your BOM.

Fixed Inductors specifications for ASPI-0418FS-4R7M-T3

Description：FIXED IND 4.7UH 1.7A 84 MOHM SMD
Series：ASPI-0418FS
Mfr：Abracon LLC
Package：Tape & Reel (TR),Cut Tape (CT)
Type：Drum Core, Wirewound
Material - Core：Ferrite
Inductance：4.7 µH
Tolerance：±20%
Current Rating (Amps)：1.7 A
Current - Saturation (Isat)：2A
Shielding：Shielded
DC Resistance (DCR)：84mOhm Max
Q @ Freq：-
Frequency - Self Resonant：60MHz
Ratings：-
Operating Temperature：-25°C ~ 120°C
Inductance Frequency - Test：100 kHz
Mounting Type：Surface Mount
Package / Case：Nonstandard
Supplier Device Package：-
Size / Dimension：0.157" L x 0.157" W (4.00mm x 4.00mm)
Height - Seated (Max)：0.071" (1.80mm)
Features：-

Fixed Inductors datasheet and documents for ASPI-0418FS-4R7M-T3

ASPI-0418FS-4R7M-T3

Fixed Inductors Overview

The ASPI-0418FS-4R7M-T3 is a shielded surface-mount power inductor from Abracon LLC. It features a drum core wirewound construction with a nominal inductance of 4.7 µH and a tolerance of ±20%. The component supports a maximum DC current of 1.7 A and has a maximum DC resistance of 84 mΩ. Measuring 4.00 mm x 4.00 mm with a height of 1.80 mm, it operates within a temperature range of -25°C to +120°C.

Fixed Inductors Feature Summary

Shielded magnetic structure minimizes electromagnetic interference
Drum core wirewound design for stable performance
Low profile surface mount package suitable for space-constrained layouts

Fixed Inductors Applications

DC-DC converter output filtering
Power supply input stages
Point-of-load regulation circuits

Fixed Inductors Procurement Notes

Verify the specific ordering suffix against the manufacturer's official datasheet to ensure correct packaging and electrical tolerances. Confirm that the requested variant matches the required current ratings and physical dimensions for the target application before finalizing procurement orders.

Fixed Inductors Selection Notes

Select this component when a shielded inductor is required to reduce magnetic field leakage in dense circuit boards. Ensure the operating environment stays within the specified temperature limits and that the load current does not exceed the rated maximums to maintain reliability.

Fixed Inductors Part Context

This part belongs to the ASPI-0418FS series of low-profile shielded SMD chip power inductors. The series offers various inductance values optimized for high-current applications, providing a compact solution for modern electronic designs requiring efficient power management components.
