ASPI-0630LR-5R6M-T15

$0.60

Description：FIXED IND 5.6UH 6A 35.5 MOHM SMD
Series：ASPI-0630LR
Mfr：Abracon LLC
Package：Tape & Reel (TR),Cut Tape (CT)

SKU:206621ac4ef1 Category: Fixed Inductors Brand: Abracon LLC

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

ASPI-0630LR-5R6M-T15 is listed in the Fixed Inductors range at ChipApex. The manufacturer field lists Abracon LLC. Its product description is FIXED IND 5.6UH 6A 35.5 MOHM SMD. Review the specifications below when checking this part for your BOM.

Fixed Inductors specifications for ASPI-0630LR-5R6M-T15

Description：FIXED IND 5.6UH 6A 35.5 MOHM SMD
Series：ASPI-0630LR
Mfr：Abracon LLC
Package：Tape & Reel (TR),Cut Tape (CT)
Type：Molded
Material - Core：Carbonyl Powder
Inductance：5.6 µH
Tolerance：±20%
Current Rating (Amps)：6:00 AM
Current - Saturation (Isat)：5A
Shielding：Shielded
DC Resistance (DCR)：35.5mOhm Max
Q @ Freq：-
Frequency - Self Resonant：-
Ratings：-
Operating Temperature：-55°C ~ 125°C
Inductance Frequency - Test：100 kHz
Mounting Type：Surface Mount
Package / Case：Nonstandard
Supplier Device Package：-
Size / Dimension：0.283" L x 0.262" W (7.20mm x 6.65mm)
Height - Seated (Max)：0.118" (3.00mm)
Features：-

Fixed Inductors datasheet and documents for ASPI-0630LR-5R6M-T15

ASPI-0630LR-5R6M-T15

Fixed Inductors Overview

The ASPI-0630LR-5R6M-T15 is a shielded surface-mount power inductor from Abracon LLC, featuring a molded alloy powder core. It provides an inductance of 5.6 µH with a tolerance of ±20%. The component supports a maximum DC current of 6 A and a saturation current of 8 A. Its maximum DC resistance is specified at 35.5 mΩ. Designed for high-frequency applications up to 3 MHz, it utilizes a nonstandard package measuring 7.2 mm in length, 6.3 mm in width, and 3 mm in height.

Fixed Inductors Feature Summary

Shielded construction minimizes electromagnetic interference and magnetic flux leakage
Alloy powder core material enables high saturation current capabilities
Low DC resistance design reduces power loss and heat generation
Suitable for automated reflow soldering processes

Fixed Inductors Applications

DC-DC converter circuits
Power supply filtering
Signal processing applications

Fixed Inductors Procurement Notes

Verify the specific ordering suffix T15 against the manufacturer datasheet to confirm packaging details. Ensure the requested quantity aligns with standard reel or cut-tape availability. Confirm RoHS compliance status matches project requirements. Cross-reference the lead time with the distributor's current stock status before finalizing orders.

Fixed Inductors Selection Notes

Select this component when a shielded inductor with high saturation current is required. The 5.6 µH value suits moderate frequency switching applications. Verify that the 6.3 x 7.2 mm footprint fits the PCB layout constraints. Consider the 35.5 mΩ resistance for efficiency calculations in low-voltage power stages.

Fixed Inductors Part Context

This part belongs to the ASPI-0630LR series of shielded surface-mount power inductors. The series offers various inductance values within the same physical envelope. These components are designed for general-purpose power electronics where space constraints and EMI reduction are critical factors.
