ASPIAIG-Q1060-6R8M-T is listed in the Fixed Inductors range at ChipApex. The manufacturer field lists Abracon LLC. Its product description is FIXED IND 6.8UH 10.5A 13MOHM SMD. Review the specifications below when checking this part for your BOM.
Fixed Inductors specifications for ASPIAIG-Q1060-6R8M-T
- Description：FIXED IND 6.8UH 10.5A 13MOHM SMD
- Series：ASPIAIG-Q1060
- Mfr：Abracon LLC
- Package：Tape & Reel (TR)
- Type：Molded
- Material - Core：Alloy Powder
- Inductance：6.8 µH
- Tolerance：±20%
- Current Rating (Amps)：10.5 A
- Current - Saturation (Isat)：15.5A
- Shielding：Shielded
- DC Resistance (DCR)：13mOhm Max
- Q @ Freq：-
- Frequency - Self Resonant：-
- Ratings：AEC-Q200
- Operating Temperature：-55°C ~ 155°C
- Inductance Frequency - Test：100 kHz
- Mounting Type：Surface Mount
- Package / Case：Nonstandard
- Supplier Device Package：-
- Size / Dimension：0.469" L x 0.433" W (11.90mm x 11.00mm)
- Height - Seated (Max)：0.236" (6.00mm)
- Features：-
Fixed Inductors datasheet and documents for ASPIAIG-Q1060-6R8M-T
Fixed Inductors Overview
The Abracon ASPIAIG-Q1060-6R8M-T is a shielded surface-mount power inductor from the ASPIAIG-Q series, designed for automotive applications. It features an alloy powder core with molded construction to minimize core losses and DC resistance. Key electrical parameters include an inductance of 6.8 µH, a maximum DC current rating of 10.5 A, and a maximum DC resistance of 13 mΩ. The component operates within a temperature range of -40°C to +125°C and holds AEC-Q200 qualification.
Fixed Inductors Feature Summary
- Shielded SMD design utilizing alloy powder molding for reduced core losses
- High current handling capability suitable for demanding power stages
- Automotive-grade reliability certified under AEC-Q200 standards
Fixed Inductors Applications
- Automotive DC-DC converters
- Power supply energy storage circuits
- Industrial power management systems
Fixed Inductors Procurement Notes
Verify the specific part number against official manufacturer documentation to confirm electrical tolerances and physical dimensions. Ensure compatibility with your PCB footprint and thermal requirements. Cross-reference with authorized distributors for availability and authenticity. Confirm that the AEC-Q200 qualification meets your specific automotive grade requirements before finalizing procurement decisions.
Fixed Inductors Selection Notes
Select this component when high current capacity and low DC resistance are critical for efficiency in automotive power stages. The 6.8 µH value suits specific filtering or energy storage needs in DC-DC conversion topologies. Consider the 10.5 A rating against peak load currents to prevent saturation. The shielded construction helps mitigate electromagnetic interference in dense layouts.
Fixed Inductors Part Context
This component belongs to the ASPIAIG-Q series of power inductors manufactured by Abracon LLC. The series offers various form factors including leaded and SMD versions, utilizing metal alloy or carbonyl powder molding. These inductors are engineered for superior power density and efficiency in commercial, transportation, medical, and industrial sectors.
Fixed Inductors Replacement Considerations
Publicly confirmed substitute part numbers are not available in the provided source data. Verify pinout and parameter compatibility if considering alternative manufacturers.
