AT25DN011-MAHFGP-Y is listed in the Memory IC range at ChipApex. The manufacturer field lists Renesas Electronics Corporation. Its product description is IC FLASH 1MBIT SPI 104MHZ 8UDFN. Review the specifications below when checking this part for your BOM.
Memory IC specifications for AT25DN011-MAHFGP-Y
- Description：IC FLASH 1MBIT SPI 104MHZ 8UDFN
- Series：-
- Mfr：Renesas Electronics Corporation
- Package：Tray
- Memory Type：Non-Volatile
- Memory Format：FLASH
- Technology：FLASH
- Memory Size：1Mbit
- Memory Organization：128K x 8
- Memory Interface：SPI
- Clock Frequency：104 MHz
- Write Cycle Time - Word, Page：8µs, 1.75ms
- Voltage - Supply：2.3V ~ 3.6V
- Operating Temperature：-40°C ~ 85°C (TC)
- Mounting Type：Surface Mount
- Package / Case：8-UFDFN Exposed Pad
- Supplier Device Package：8-UDFN (2x3)
- Access Time：-
- Grade：-
- Qualification：-
Memory IC datasheet and documents for AT25DN011-MAHFGP-Y
Memory IC Overview
The AT25DN011-MAHFGP-Y is a 1 Mbit Serial NOR Flash memory device manufactured by Renesas Electronics Corporation. It features an SPI interface with a maximum clock frequency of 104 MHz and supports Dual Output Read modes. The device operates on a single 2.3 V to 3.6 V supply and includes active read currents up to 18 mA. It utilizes an 8-UDFN (2x3 mm) package with an exposed pad for surface mount installation. The memory organization is 128 K x 8 bits, covering a temperature range from -40°C to +85°C.
Memory IC Feature Summary
- Supports Single, Dual, and Quad SPI modes for flexible data transfer rates
- High-speed serial interface compatible with standard SPI protocols
- Compact 8-pin UDFN package suitable for space-constrained designs
Memory IC Applications
- Consumer electronics firmware storage
- Industrial control system code execution
- Embedded systems requiring non-volatile program storage
Memory IC Procurement Notes
Verify the specific suffix MAHFGP-Y against official Renesas documentation to confirm package type and tape/reel specifications. Ensure compatibility with existing PCB footprints for the 8-UDFN form factor. Confirm RoHS compliance status through current manufacturer declarations before finalizing procurement orders.
Memory IC Selection Notes
Select this component when a 1 Mbit capacity is required with high-speed SPI access. Consider the 2.3 V minimum operating voltage for low-power applications. Evaluate the 8-UDFN package dimensions against available board space constraints. Verify that the target system supports the necessary SPI modes for optimal performance.
Memory IC Part Context
This part belongs to the AT25DN011 series of Serial NOR Flash memories designed for high-volume consumer applications. The series offers code execution capabilities directly from flash memory. It is engineered for reliability in embedded environments requiring persistent storage for microcontroller programs.
Memory IC Replacement Considerations
AT25DF011-MAHN-T is listed as a similar substitute option. Verify electrical parameters and pinout compatibility before substitution.
