AT45DB321D-MWU

Memory IC Overview

The AT45DB321D is a 32Mb serial flash memory device featuring the Atmel RapidS interface, supporting SPI modes 0 and 3 with clock frequencies up to 66MHz. It operates on a single supply voltage of either 2.5V to 3.6V or 2.7V to 3.6V. The memory array consists of 8,192 pages, each containing either 512 bytes or 528 bytes, with user-configurable page sizes. Two SRAM data buffers of matching size facilitate continuous data streaming and efficient programming operations.

Memory IC Feature Summary

• Dual SRAM data buffers enable receiving data while reprogramming the main memory array for high-throughput applications.
• Supports flexible erase options including page, block, sector, and chip-level erasure for versatile data management.
• Integrated hardware and software protection features include sector lockdown and a dedicated security register.
• Continuous read capability allows seamless access across the entire memory array without delays at page boundaries.

Memory IC Applications

• Digital voice storage
• Image storage
• Program code shadowing
• Data storage

Memory IC Procurement Notes

Verify the specific operating voltage range (2.5V or 2.7V) required for your design before ordering, as the AT45DB321D series includes variants with different minimum voltage thresholds. Confirm the package type matches your PCB footprint requirements. Ensure compatibility with the host processor's SPI interface speeds, as the device supports up to 66MHz. Check for RoHS compliance if environmental regulations apply to your manufacturing process.

Memory IC Selection Notes

Select this component when sequential access via a serial interface is preferred over parallel random access to reduce pin count and switching noise. The dual buffer architecture makes it suitable for applications requiring continuous data streams, such as audio or video buffering. Consider the configurable page size (512 vs 528 bytes) based on system alignment needs. The industrial temperature range ensures reliability in demanding environments.

Memory IC Part Context

The AT45DB321D belongs to the Atmel DataFlash family, designed for high-density code and data storage. It utilizes a proprietary RapidS serial interface that is compatible with standard SPI protocols. This family emphasizes low power consumption and simplified hardware layout by minimizing external connections compared to traditional parallel NOR flash devices.

Memory IC Replacement Considerations

Check datasheets for AT45DB321E or AT45DB161E for similar architectures but verify voltage ranges and density differences. Ensure any substitute supports the same RapidS/SPI command set and page size configurations to maintain software compatibility.
