Product Detailed Parameters
- Description：IC MCU 32BIT 32KB FLASH 32VQFN
- Series：SAM HA1, Functional Safety (FuSa)
- Mfr：Microchip Technology
- Package：Tape & Reel (TR)
- Core Processor：ARM® Cortex®-M0+
- Core Size：32-Bit Single-Core
- Speed：48MHz
- Connectivity：I2C, LINbus SBC, SPI, UART/USART
- Peripherals：Brown-out Detect/Reset, DMA, POR, PWM, WDT
- Number of I/O：19
- Program Memory Size：32KB (16K x 16)
- Program Memory Type：FLASH
- EEPROM Size：1K x 8
- RAM Size：4K x 8
- Voltage - Supply (Vcc/Vdd)：0V ~ 3.8V
- Data Converters：A/D 6x12b; D/A 1x10b
- Oscillator Type：Internal
- Operating Temperature：-40°C ~ 105°C (TA)
- Mounting Type：Surface Mount, Wettable Flank
- Supplier Device Package：32-VQFN (5x5)
- Package / Case：32-VFQFN Exposed Pad
- Grade：Automotive
- Qualification：AEC-Q100
