Product Detailed Parameters
- Description：IC MCU 8BIT 4KB FLASH 14TSSOP
- Series：tinyAVR® 2
- Mfr：Microchip Technology
- Package：Tape & Reel (TR),Cut Tape (CT)
- Core Processor：AVR
- Core Size：8-Bit
- Speed：20MHz
- Connectivity：I2C, SPI, UART/USART
- Peripherals：Brown-out Detect/Reset, POR, PWM, WDT
- Number of I/O：12
- Program Memory Size：4KB (4K x 8)
- Program Memory Type：FLASH
- EEPROM Size：128 x 8
- RAM Size：512 x 8
- Voltage - Supply (Vcc/Vdd)：1.8V ~ 5.5V
- Data Converters：A/D 9x12b
- Oscillator Type：Internal
- Operating Temperature：-40°C ~ 85°C (TA)
- Mounting Type：Surface Mount
- Supplier Device Package：14-TSSOP
- Package / Case：14-TSSOP (0.173", 4.40mm Width)
- Grade：-
- Qualification：-
Download product information
Overview
The ATtiny424-XUR is an 8-bit AVR microcontroller from the tinyAVR 2 family, featuring a 20-pin TSSOP package. It includes 4 KB of Flash memory, 512 bytes of SRAM, and 128 bytes of EEPROM. The device operates at a maximum clock frequency of 20 MHz with a supply voltage range of 1.8V to 5.5V. Key peripherals include a 12-bit differential ADC with PGA, two USARTs, SPI, TWI, and an Event System.
Feature Summary
- Features a high-performance low-power AVR CPU with hardware multiplier
- Includes a 12-bit differential ADC with Programmable Gain Amplifier (PGA)
- Supports single-pin Unified Program and Debug Interface (UPDI)
- Provides flexible analog features and advanced digital peripherals
Applications
- Industrial control systems
- Battery-powered devices
- Sensor interfaces
- General-purpose embedded applications
Procurement Notes
Verify the specific ordering suffix 'XUR' corresponds to the TSSOP-20 package and industrial temperature range (-40°C to +85°C). Confirm that the datasheet revision matches the required specifications for your design. Ensure compatibility with existing toolchains and programming interfaces before finalizing procurement.
Selection Notes
Select this component when a balance of processing power and peripheral richness is needed in a compact 20-pin form factor. The tinyAVR 2 architecture offers vertical migration within the family without code modification. Consider the 12-bit ADC and event system for applications requiring precise analog signal acquisition and deterministic timing.
Part Context
This part belongs to the tinyAVR 2 family, which shares architectural similarities with other members like the ATtiny426 and ATtiny427. These devices are designed for pin-to-pin compatibility across different pin counts and memory sizes, facilitating easy upgrades or downgrades in product designs while maintaining software compatibility.
Replacement Considerations
Direct replacements within the same package and feature set include the ATtiny426-XUR and ATtiny427-XUR. Verify that the alternative part number meets the specific memory size requirements and peripheral availability needed for the application.
