AUU157-4706

$7.23

Description：CMC 10MH 1.5A 2LN TH
Series：-
Mfr：Allied Components International
Package：Tray

SKU:df0b1192412f Category: Common Mode Chokes Brand: Allied Components International

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：CMC 10MH 1.5A 2LN TH
Series：-
Mfr：Allied Components International
Package：Tray
Filter Type：-
Number of Lines：2
Current Rating (Max)：1.5A
DC Resistance (DCR) (Max)：220mOhm Max
Voltage Rating - DC：-
Voltage Rating - AC：-
Operating Temperature：-55°C ~ 105°C
Ratings：-
Approval Agency：-
Features：-
Mounting Type：Through Hole
Size / Dimension：0.906" L x 0.768" W (23.00mm x 19.50mm)
Height (Max)：1.083" (27.50mm)
Package / Case：Vertical, 4 PC Pin
Inductance @ Frequency：10 mH @ 1 kHz
Impedance @ Frequency：-
Qualification：-
Grade：-

Download product information

AUU157-4706

Overview

The AUU157-4706 is a two-line common mode choke manufactured by Allied Components International. It features through-hole mounting and is rated for a current of 1.5A with a DC resistance of 220mOhm. The inductance value is specified as 10 mH at a test frequency of 1 kHz.

Feature Summary

Provides common mode noise suppression for two-line circuits
Designed for through-hole PCB integration
Constructed for industrial and commercial magnetic applications

Applications

Telecommunications equipment filtering
Power conversion circuit protection
Test equipment signal integrity maintenance

Procurement Notes

Verify the specific inductance tolerance and saturation current requirements against your design specifications before ordering. Confirm that the through-hole footprint dimensions align with your PCB layout constraints. Ensure compliance with RoHS3 standards if required by your manufacturing process. Cross-reference the manufacturer part number to avoid confusion with similar series components.

Selection Notes

Select this component when a 10 mH common mode choke is required for low-current applications up to 1.5A. Consider the 220mOhm DC resistance impact on power loss within the circuit design. Evaluate the physical size constraints for through-hole placement relative to other board components. Verify compatibility with the operating frequency range of the target application.

Part Context

Allied Components International specializes in standard and custom magnetic components for networking, telecommunications, and power conversion markets. This part belongs to their line of industry-standard chokes designed for commercial and industrial use. The company has been manufacturing these components since 1992, focusing on quality and reliability for critical electronic systems.

Replacement Considerations

Check for direct substitutes with identical 10 mH inductance and 1.5A current ratings. Ensure replacement parts maintain the same through-hole package style and pin configuration. Verify that alternative common mode chokes meet the same DC resistance and frequency response characteristics.
