AV-8.000MAHE-T

$0.70

Description：3.2X2.5 GLASS SEAL MHZ QUARTZ XT
Series：AV
Mfr：TXC CORPORATION
Package：Tape & Reel (TR),Cut Tape (CT)

SKU:604e11407f53 Category: Crystals Brand: TXC CORPORATION

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

AV-8.000MAHE-T is listed in the Crystals range at ChipApex. The manufacturer field lists TXC CORPORATION. Its product description is 3.2X2.5 GLASS SEAL MHZ QUARTZ XT. Review the specifications below when checking this part for your BOM.

Crystals specifications for AV-8.000MAHE-T

Description：3.2X2.5 GLASS SEAL MHZ QUARTZ XT
Series：AV
Mfr：TXC CORPORATION
Package：Tape & Reel (TR),Cut Tape (CT)
Type：MHz Crystal
Frequency：-
Frequency Stability：±30ppm
Frequency Tolerance：±30ppm
Load Capacitance：12pF
ESR (Equivalent Series Resistance)：-
Operating Mode：Fundamental
Operating Temperature：-40°C ~ 85°C
Ratings：AEC-Q200
Mounting Type：Surface Mount
Package / Case：4-SMD, No Lead
Size / Dimension：0.126" L x 0.098" W (3.20mm x 2.50mm)
Height - Seated (Max)：0.035" (0.90mm)

Crystals datasheet and documents for AV-8.000MAHE-T

AV-8.000MAHE-T

Crystals Overview

The AV-8.000MAHE-T is a quartz crystal resonator manufactured by TXC Corporation, designed for automotive applications with AEC-Q200 certification. It operates at a fundamental frequency of 8 MHz and utilizes a glass-sealed package construction to ensure environmental stability. The component features a load capacitance of 12 pF and offers a frequency tolerance of ±30 ppm across the specified temperature range. It is housed in a compact 4-SMD, no lead surface-mount package measuring 3.2 mm by 2.5 mm, suitable for automated assembly processes.

Crystals Feature Summary

AEC-Q200 certified for automotive reliability standards
Glass-sealed package construction for enhanced durability
Surface-mount design with no lead configuration

Crystals Applications

Automotive electronic control units
In-vehicle infotainment systems
Automotive sensor modules

Crystals Procurement Notes

Verify the specific suffix 'T' indicates tape-and-reel packaging when placing orders. Confirm that the AEC-Q200 qualification meets your project's automotive grade requirements. Ensure the 12 pF load capacitance matches your circuit design specifications before procurement. Check current availability status as supply may be restricted.

Crystals Selection Notes

Select this component when an 8 MHz reference signal is required for automotive-grade circuits. The 3.2x2.5 mm footprint allows for space-constrained PCB layouts. Consider the ±30 ppm tolerance if tighter frequency accuracy is not critical. The glass-seal technology provides superior protection against moisture compared to standard epoxy packages.

Crystals Part Context

This part belongs to the AV series of crystals from TXC Corporation, which are specifically engineered for automotive electronics. The series emphasizes high reliability and resistance to harsh environmental conditions typical in vehicle environments. The AV-8.000MAHE-T represents a standard frequency option within this specialized automotive lineup.
