AWCS001207071N3B00 is listed in the Fixed Inductors range at ChipApex. The manufacturer field lists Pulse Electronics. Its product description is INDUCTOR RF. Review the specifications below when checking this part for your BOM.
Fixed Inductors specifications for AWCS001207071N3B00
- Description：INDUCTOR RF
- Series：AWCS
- Mfr：Pulse Electronics
- Package：Tape & Reel (TR)
- Type：Drum Core, Wirewound
- Material - Core：Ceramic
- Inductance：1.3 nH
- Tolerance：±0.1nH
- Current Rating (Amps)：640 mA
- Current - Saturation (Isat)：-
- Shielding：Unshielded
- DC Resistance (DCR)：140mOhm Max
- Q @ Freq：10 @ 250MHz
- Frequency - Self Resonant：10.4GHz
- Ratings：-
- Operating Temperature：-40°C ~ 125°C
- Inductance Frequency - Test：250 MHz
- Mounting Type：Surface Mount
- Package / Case：0402 (1005 Metric)
- Supplier Device Package：402
- Size / Dimension：0.047" L x 0.025" W (1.19mm x 0.64mm)
- Height - Seated (Max)：0.026" (0.66mm)
- Features：-
Fixed Inductors datasheet and documents for AWCS001207071N3B00
Fixed Inductors Overview
The AWCS001207071N3B00 is an unshielded surface-mount RF inductor from Pulse Electronics, part of the AWCS series. It features a wire-wound core and measures 1.19 mm x 0.7 mm x 0.66 mm. The component has an inductance of 1 nH with a tolerance of ±0.1 nH. It supports a maximum DC current of 1.36 A and has a maximum DC resistance of 45 mOhms. The self-resonant frequency is 12.7 GHz at a test frequency of 250 MHz, with a minimum Q factor of 16. It operates between -40°C and +125°C and holds AEC-Q200 qualification.
Fixed Inductors Feature Summary
- AEC-Q200 qualified for automotive reliability standards
- Unshielded wire-wound construction for minimal magnetic interference
- High self-resonant frequency suitable for ultra-high-frequency applications
Fixed Inductors Applications
- Automotive RF circuits requiring AEC-Q200 compliance
- Ultra-high-frequency signal filtering and impedance matching
- Compact SMD layouts in mobile or IoT devices
Fixed Inductors Procurement Notes
Verify the specific suffix B00 against official datasheets to confirm the exact tolerance and packaging details. Confirm RoHS status and lead times directly with authorized distributors. Ensure the supplier provides traceability documentation required for automotive-grade components.
Fixed Inductors Selection Notes
Select this component when a 1 nH inductance with tight ±0.1 nH tolerance is required. The high current rating of 1.36 A makes it suitable for power-sensitive RF paths. The small 0402 footprint allows for dense PCB layouts in space-constrained designs.
Fixed Inductors Part Context
This part belongs to the AWCS series of RF inductors by Pulse Electronics. It shares the standard 0402 package dimensions with other variants in the family but differs in electrical parameters such as inductance value and tolerance codes defined by the model suffix.
Fixed Inductors Replacement Considerations
Cross-reference with Chilisin part CS0402-1N0B-AU, which is listed as an alias. Verify pin compatibility and electrical specifications before substitution.
