AWH 14A-0502-T

Headers, Male Pins Overview

The AWH 14A-0502-T is a male header connector from the ASSMANN WSW AWH series, designed for through-hole mounting on printed circuit boards. It features a 14-position configuration with two rows and a 2.54 mm (0.100 inch) pitch. The component utilizes brass contacts with gold plating over nickel to ensure reliable signal transmission. Constructed with a polybutylene terephthalate (PBT) housing, it supports a maximum voltage of 250V and a current rating of 3A. The operating temperature range spans from -40°C to 105°C, and the unit complies with RoHS standards.

Headers, Male Pins Feature Summary

• Provides secure electrical interconnection via through-hole solder termination
• Features gold-plated brass contacts for enhanced conductivity and corrosion resistance
• Utilizes flame-retardant PBT housing material for thermal stability

Headers, Male Pins Applications

• General-purpose PCB-to-PCB interconnections
• Industrial control system wiring harnesses
• Consumer electronics internal board connections

Headers, Male Pins Procurement Notes

Verify the specific orientation suffix in the part number to confirm right-angle versus straight pin configuration, as variations exist within the AWH series. Ensure compatibility with mating female headers regarding pitch and row count. Confirm RoHS compliance status if required by project specifications. Cross-reference the manufacturer datasheet for precise mechanical dimensions before finalizing procurement.

Headers, Male Pins Selection Notes

Select this component when a 14-pin, two-row male header is required for rigid PCB assembly. The 2.54 mm pitch ensures compatibility with standard DIP packages and ribbon cables. Consider the through-hole mounting method for robust mechanical retention compared to surface-mount alternatives. Verify that the 3A current rating meets the application's power requirements.

Headers, Male Pins Part Context

This connector belongs to the AWH series of rectangular connectors manufactured by ASSMANN WSW Components. The series is characterized by its DIN 41651 form factor compatibility and versatile mounting options. The AWH 14A-0502-T specifically addresses applications requiring medium-density interconnects with high reliability and standardized spacing.

Headers, Male Pins Replacement Considerations

Compatible substitutes include generic 14-pin, 2.54mm pitch male headers from other manufacturers such as Molex or Samtec, provided mechanical dimensions and contact plating specifications match exactly.
