AWHW 30G-0202-R

Headers, Male Pins Overview

The AWHW 30G-0202-R is a 30-position IDC header connector from the Assmann WSW AWHW series. It features a 2.54 mm (0.100 inch) pin spacing and a dual-row configuration with male pins. Designed for through-hole mounting, it utilizes a push-pull fastening mechanism and includes a four-wall shielded cover. The contacts are made of brass with gold plating on the mating interface, while the housing is constructed from glass-fiber reinforced PBT rated UL94 V-0. Rated for 3A current and 250V AC, it operates within a temperature range of -40°C to 105°C.

Headers, Male Pins Feature Summary

• Dual-row male header design with integrated four-wall shielding for signal protection
• Push-pull fastening system ensures secure mechanical connection without screws
• Gold-plated brass contacts provide reliable conductivity and corrosion resistance
• UL94 V-0 rated PBT insulation supports high-temperature environments up to 105°C

Headers, Male Pins Applications

• IDC cable-to-board interconnections in industrial control systems
• Signal routing in telecommunications equipment backplanes
• Internal wiring harnesses for automated machinery and motion terminals
• Data transmission links in server rack infrastructure

Headers, Male Pins Procurement Notes

Verify that the suffix 'R' corresponds to the specific right-angle or straight orientation variant required by your PCB layout, as orientation variants exist within this series. Confirm that the 30-position count matches your circuit density needs. Ensure the mating cable assembly is compatible with the 2.54mm pitch and IDC termination style. Check RoHS compliance status if environmental regulations apply to your final product assembly.

Headers, Male Pins Selection Notes

Select this component when a robust, shielded IDC header is needed for high-density signal routing. The 30-pin capacity suits complex data buses. The push-pull feature simplifies assembly compared to screw-lock alternatives. Consider the operating temperature range and current rating against your application's thermal and electrical loads. Verify PCB hole dimensions align with the through-hole pin specifications.

Headers, Male Pins Part Context

This part belongs to the AWHW series of IDC connectors, which are widely used for ribbon cable connections. The series offers various pin counts and orientations, including both straight and right-angle configurations. The 'G' typically denotes a standard height or specific housing profile, while the 'R' suffix indicates a specific mechanical orientation variant. These connectors are designed for reliable performance in demanding electronic environments.

Headers, Male Pins Replacement Considerations

AWHW 30G-0202-LC: Verified substitute with identical 30-position, 2.54mm pitch, and dual-row male configuration. Note that the 'LC' suffix may indicate a different housing color or slight dimensional variation; verify mechanical fit before adoption.
