AWSPL0806P-R47M-C

$3.40

Description：470nH 23A 1.90mOHms THT inductor
Series：AWSPL
Mfr：AW Coil
Package：Tape & Reel (TR)

SKU:259f0e423773 Category: Fixed Inductors Brand: AW Coil

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

AWSPL0806P-R47M-C is listed in the Fixed Inductors range at ChipApex. The manufacturer field lists AW Coil. Its product description is 470nH 23A 1.90mOHms THT inductor. Review the specifications below when checking this part for your BOM.

Fixed Inductors specifications for AWSPL0806P-R47M-C

Description：470nH 23A 1.90mOHms THT inductor
Series：AWSPL
Mfr：AW Coil
Package：Tape & Reel (TR)
Type：-
Material - Core：-
Inductance：0.47 µH
Tolerance：±20%
Current Rating (Amps)：23 A
Current - Saturation (Isat)：38A
Shielding：Shielded
DC Resistance (DCR)：1.9mOhm
Q @ Freq：-
Frequency - Self Resonant：-
Ratings：-
Operating Temperature：-40°C ~ 125°C
Inductance Frequency - Test：100 kHz
Mounting Type：Through Hole
Package / Case：Radial, Vertical
Supplier Device Package：Radial Lead
Size / Dimension：0.323" L x 0.323" W (8.20mm x 8.20mm)
Height - Seated (Max)：0.276" (7.00mm)
Features：-

Fixed Inductors datasheet and documents for AWSPL0806P-R47M-C

AWSPL0806P-R47M-C

Fixed Inductors Overview

The AW Coil AWSPL0806P-R47M-C is a surface-mount shielded power inductor from the AWSPL series. It features a composite core construction and a closed magnetic circuit design to minimize electromagnetic interference. The nominal inductance is 0.47 µH with a tolerance of ±20%. The component supports a saturation current of 13 A and an RMS current rating of 9.5 A. It utilizes a standard SMD package with dimensions of 8.0 mm x 6.0 mm x 6.0 mm, suitable for automated assembly processes.
