AZ16000003

Crystals Overview

The AZ16000003 is a passive surface-mount crystal manufactured by TXC Corporation. It operates at a fundamental frequency of 16 MHz with a load capacitance of 10 pF. The component utilizes an ultra-miniature package measuring 2.5 mm in length and 2 mm in width, weighing approximately 13 mg. It supports reeled packaging for automated assembly processes. The device is designed to function reliably within an operating temperature range spanning from -40°C to +85°C, ensuring stability across varied environmental conditions.

Crystals Feature Summary

• Ultra-miniature surface-mount design for compact circuit integration
• High precision frequency stability at 16 MHz
• Robust thermal performance across extended industrial temperature ranges

Crystals Applications

• Portable digital devices requiring precise timing
• Consumer electronics with space constraints
• Industrial control systems needing stable clock signals

Crystals Procurement Notes

Verify the specific load capacitance requirement of 10 pF against your circuit design specifications before procurement. Confirm that the operating temperature range of -40°C to +85°C aligns with your application's environmental demands. Ensure compatibility with the 2.5 mm x 2 mm footprint during PCB layout validation. Cross-reference the manufacturer part number AZ16000003 with official TXC documentation to confirm current production status and availability.

Crystals Selection Notes

Select this component when a small form factor is critical for board space optimization. Choose the AZ16000003 if the application requires a standard 16 MHz reference frequency with moderate load capacitance. Consider this part for designs necessitating operation in colder environments down to -40°C. Evaluate the SMD reel packaging benefits for high-volume manufacturing efficiency compared to bulk options.

Crystals Part Context

This crystal belongs to the AZ series from TXC Corporation, which focuses on ultra-miniature and thin profile components. The series emphasizes low series resistance and high Q-factor characteristics suitable for modern electronic devices. As a passive resonator, it provides the necessary oscillation frequency without internal active circuitry, relying on external oscillator circuits for signal generation.

Crystals Replacement Considerations

The 8Z16070017 serves as a potential substitute within the same manufacturer lineup. Both parts share identical physical dimensions of 2.5 mm x 2 mm and operate at 16 MHz. Verify that the electrical parameters, particularly load capacitance and frequency tolerance, match your specific circuit requirements before implementing any substitution.
