AZ9415-01G

AZ9415-01G is listed in the Tvs Diodes range at ChipApex. The manufacturer field lists Amazing. Its product description is TVS DEVICE LOW SPEED 1-CH 15V. Review the specifications below when checking this part for your BOM.

Tvs Diodes specifications for AZ9415-01G

• Description：TVS DEVICE LOW SPEED 1-CH 15V
• Series：TVS/ESD/EOS
• Mfr：Amazing
• Package：Tape & Reel (TR)
• Type：-
• Bidirectional Channels：1
• Voltage - Reverse Standoff (Typ)：15V (Max)
• Voltage - Breakdown (Min)：16.7V
• Voltage - Clamping (Max) @ Ipp：18V (Typ)
• Current - Peak Pulse (10/1000µs)：30A (8/20µs)
• Power - Peak Pulse：-
• Power Line Protection：No
• Applications：Power Line
• Capacitance @ Frequency：600pF @ 1MHz
• Operating Temperature：-55°C ~ 125°C
• Mounting Type：Surface Mount
• Package / Case：SOD-123
• Supplier Device Package：SOD-123
• Unidirectional Channels：-
• Grade：-
• Qualification：-

Tvs Diodes datasheet and documents for AZ9415-01G
