B-06-RTF-25

Overview

The KEMET B-06-RTF-25 is a radial ferrite bead designed for signal line filtering. It features a DC resistance of 40 Ohms and supports a maximum current of 5 Amperes. The component operates within a temperature range of -55°C to +125°C. It utilizes a bead lead termination style for through-hole mounting.

Feature Summary

• Provides electromagnetic interference suppression for signal lines
• Features high current handling capability suitable for power applications
• Utilizes flexible soft leads for mechanical stability

Applications

• Signal line EMI filtering
• Power line noise suppression
• Electromagnetic compatibility (EMC) circuits

Procurement Notes

Verify the specific impedance value at the required frequency against application needs, as ferrite characteristics vary with frequency. Confirm that the 5A current rating aligns with the operational load. Ensure the radial package dimensions fit the target PCB layout. Check for RoHS compliance status if restricted substances are prohibited in the final assembly.

Selection Notes

Select this component when high current capacity is required alongside significant impedance for noise reduction. The radial form factor is preferred for applications requiring robust mechanical connections or wire-wrapping. Consider the thermal performance at maximum current loads to ensure reliability under continuous operation conditions.

Part Context

This part belongs to the KEMET B-series of ferrite beads, which are characterized by their bead lead construction. These components are engineered for effective attenuation of high-frequency noise in both power and signal paths, offering a compact solution for EMC requirements in industrial and consumer electronics.

Replacement Considerations

Direct substitutes include other radial ferrite beads with similar 40 Ohm impedance and 5A current ratings. Verify that alternative parts match the physical lead spacing and overall dimensions to ensure compatibility with existing footprints.
