B080MB5S

Overview

The B080MB5S is a surface mount bandpass filter manufactured by Knowles Dielectric Labs. It operates at a center frequency of 8 GHz with an insertion loss of 2 dB. The component features a 50 Ohm impedance and utilizes ceramic substrate filtering technology. Designed for board mounting, it supports SMD/SMT termination types. This signal conditioning device is part of the Bandpass series and is suitable for applications requiring precise RF frequency selection within microwave communication systems.

Feature Summary

• Utilizes ceramic substrate technology for stable RF performance
• Provides precise bandpass filtering at 8 GHz center frequency
• Designed for surface mount integration on printed circuit boards

Applications

• Microwave communication systems
• RF signal conditioning circuits
• Wireless infrastructure equipment

Procurement Notes

Verify the specific datasheet revision and mechanical dimensions against your PCB layout requirements before finalizing the design. Confirm that the 50 Ohm impedance matches your system interface specifications. Ensure the operating temperature range aligns with your environmental conditions. Cross-reference the manufacturer's latest documentation to confirm current production status and availability constraints.

Selection Notes

Select this component when a fixed 8 GHz center frequency is required for signal isolation. The 2 dB insertion loss indicates moderate signal attenuation, which should be accounted for in link budget calculations. Consider the physical footprint and soldering profile compatibility with your assembly process. Evaluate if the ceramic substrate construction meets your thermal and mechanical reliability standards for the intended application environment.

Part Context

This component belongs to the Knowles Dielectric Labs Bandpass filter series, specifically designed for high-frequency signal processing. It falls under the broader category of signal conditioning devices used in RF engineering. The product line emphasizes compact surface mount solutions for modern electronic designs requiring reliable frequency selection in crowded spectral environments.

Replacement Considerations

Public confirmed substitute part numbers are not available in the provided source material.
