B12H1UY--20D000134U1930

Overview

The B12H1UY--20D000134U1930 is an amber surface-mount LED manufactured by Harvatek Corporation. It features a right-angle 2-SMD package with dimensions of 1.60mm length and 0.80mm width, and a maximum height of 0.50mm. The component emits light at a peak wavelength of 590nm with a typical forward voltage of 2V. It provides an intensity of 25mcd when tested at 20mA, offering a viewing angle of 120 degrees.

Feature Summary

• Right-angle surface mount configuration for compact PCB routing
• Diffused lens design for uniform light distribution
• Amber color emission suitable for status indication

Applications

• Electronic device status indicators
• Control panel signal lights
• Consumer appliance front panels

Procurement Notes

Verify the specific suffix against the manufacturer's current datasheet to ensure compatibility with required packaging formats and moisture sensitivity levels. Confirm that the right-angle lead configuration aligns with the target PCB footprint design before finalizing procurement orders.

Selection Notes

Select this component when a low-profile, right-angle LED is required for space-constrained designs. The diffused amber lens provides clear visibility without harsh glare. Ensure the 2V forward voltage drop is compatible with the driving circuit's supply voltage and current limiting requirements.

Part Context

This part belongs to Harvatek's SMD LED lineup, which includes various colors and package styles. The B12H1 series specifically denotes right-angle configurations, distinguishing it from standard top-view or side-view LEDs in the manufacturer's catalog.

Replacement Considerations

Direct substitutes must match the right-angle 2-SMD form factor and amber spectral output. Verify pinout orientation and mechanical dimensions to ensure fit within the existing PCB layout constraints.
