B17T2UOUG20D000114U1930

$0.16

Description：LED RED/YLW-GRN CLEAR 0805 SMD
Series：B17T2UOUG20
Mfr：Harvatek Corporation
Package：Tape & Reel (TR),Cut Tape (CT)

SKU:02680e11bdd9 Category: LED Indication - Discrete Brand: Harvatek Corporation

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：LED RED/YLW-GRN CLEAR 0805 SMD
Series：B17T2UOUG20
Mfr：Harvatek Corporation
Package：Tape & Reel (TR),Cut Tape (CT)
Color：Red, Yellow-Green
Configuration：Independent
Lens Color：-
Lens Transparency：Clear
Millicandela Rating：112.5mcd Red, 45mcd Yellow-Green
Lens Style：Rectangle with Flat Top
Lens Size：1.40mm x 1.30mm
Voltage - Forward (Vf) (Typ)：2V Red, 2.1V Yellow-Green
Current - Test：20mA Red, 20mA Yellow-Green
Viewing Angle：118°, 120°, 120°, 125°
Mounting Type：Surface Mount
Wavelength - Dominant：631nm Red, 571nm Yellow-Green
Wavelength - Peak：639nm Red, 573nm Yellow-Green
Features：-
Package / Case：0805 (2012 Metric)
Supplier Device Package：805
Size / Dimension：2.00mm L x 1.30mm W
Height (Max)：0.60mm
Grade：-
Qualification：-

Download product information

B17T2UOUG20D000114U1930

Overview

The B17T2UOUG20D000114U1930 is a surface-mount LED manufactured by Harvatek Corporation, designed for indicator applications. It features a green diffused lens in an 0805 (2012 metric) package with dimensions of 2.00mm length, 1.30mm width, and a maximum height of 0.90mm. The component emits light at a peak wavelength of 525nm with a dominant wavelength of 515nm. Typical forward voltage is 3V at a test current of 20mA. The device offers a viewing angle of 130 degrees and a luminous intensity of 140mcd. It complies with RoHS3 standards and has a moisture sensitivity level of 2A.
