B1911UYG-20D000114U1930

Overview

The B1911UYG-20D000114U1930 is a surface-mount LED indicator manufactured by Harvatek Corporation. It emits orange light with a peak wavelength of 611nm and a dominant wavelength of 605nm. The component utilizes a 0603 (1608 metric) package, measuring 1.60mm in length, 0.80mm in width, and a maximum height of 0.70mm. It features a diffused lens with a rectangular shape and flat top design. Electrical characteristics include a typical forward voltage of 2V at a test current of 20mA, producing an intensity of 45mcd. Viewing angles are specified as 125° and 128°. The device complies with RoHS standards and has a Moisture Sensitivity Level of 2A.

Feature Summary

• Orange color emission with diffused lens for uniform light distribution
• Compact 0603 surface-mount package suitable for space-constrained designs
• RoHS compliant construction for environmental safety

Applications

• Status indication on electronic circuit boards
• Panel mount indicators for consumer electronics
• Signal status display in industrial control equipment

Procurement Notes

Verify the exact part number suffix against official manufacturer documentation to ensure correct lens type and binning specifications. Confirm moisture sensitivity level handling requirements during storage and assembly processes. Check for specific packaging options such as tape and reel quantities if available from authorized distributors. Ensure compliance with regional regulatory standards applicable to the final product deployment.

Selection Notes

Select this component when an orange visual indicator is required in a compact form factor. Consider the 0603 footprint constraints and the specific viewing angle requirements of the application. Evaluate the forward voltage drop against the driving circuit capabilities. Verify that the diffused lens characteristic meets the visibility needs of the end-user interface.

Part Context

This component belongs to the Harvatek Corporation discrete LED indicator series. It is designed for general-purpose signaling applications where small size and reliable performance are prioritized. The product line offers various colors and package sizes to support diverse electronic design requirements.

Replacement Considerations

Consult official cross-reference lists or manufacturer substitution guides for verified equivalent parts. Do not assume compatibility based solely on package dimensions or nominal color. Verify electrical parameters and mechanical tolerances before implementing any alternative components.
