Product Detailed Parameters
- Description：3.0(L)X2.5(W)X1.5(H) MM
- Series：*
- Mfr：Harvatek Corporation
- Package：Tape & Reel (TR),Cut Tape (CT)
- Color：-
- Configuration：-
- Lens Color：-
- Lens Transparency：-
- Millicandela Rating：-
- Lens Style：-
- Lens Size：-
- Voltage - Forward (Vf) (Typ)：-
- Current - Test：-
- Viewing Angle：-
- Mounting Type：-
- Wavelength - Dominant：-
- Wavelength - Peak：-
- Features：-
- Package / Case：-
- Supplier Device Package：-
- Size / Dimension：-
- Height (Max)：-
- Grade：-
- Qualification：-
Download product information
Overview
The B25U2UOUG20C780112U1930 is a surface-mount LED manufactured by Harvatek Corporation. It features a compact package with dimensions of 3.0 mm in length, 2.5 mm in width, and 1.5 mm in height. The component operates within a temperature range of -40°C to 85°C. It complies with RoHS3 standards and has a Moisture Sensitivity Level (MSL) rating of 5A, allowing for a 24-hour exposure limit during reflow soldering processes.
Feature Summary
- Compact surface-mount design suitable for space-constrained applications
- Operates reliably across a wide industrial temperature range
- Compliant with RoHS3 environmental regulations
Applications
- Consumer electronics indicator lighting
- Industrial control panel status signals
- Automotive interior illumination components
Procurement Notes
Verify the specific color output and forward voltage parameters against the official datasheet before integration, as these values are not provided in the summary data. Confirm that the MSL 5A rating aligns with your facility's floor life management protocols to prevent moisture-induced damage during assembly. Ensure storage conditions meet the manufacturer's requirements prior to use.
Selection Notes
Select this component when a small form factor is required alongside broad thermal stability. The 3.0x2.5mm footprint offers a balance between visibility and board space efficiency. Consider the MSL 5A classification if your manufacturing process involves extended exposure to ambient humidity before soldering.
Part Context
Harvatek Corporation specializes in surface-mount LEDs for diverse electronic applications. This part belongs to their standard SMD LED portfolio, designed for reliable performance in consumer and industrial devices. The company focuses on providing compact, high-quality optoelectronic solutions for global OEM manufacturers.
Replacement Considerations
No public substitute part numbers are confirmed for this specific model. Cross-referencing requires matching the 3.0x2.5x1.5mm package, electrical characteristics, and mounting orientation from the official datasheet.
