Product Detailed Parameters
- Description：DIODE SCHOTTKY 60V 3A SMAF
- Series：-
- Mfr：Diodes Incorporated
- Package：Bulk
- Technology：Schottky
- Voltage - DC Reverse (Vr) (Max)：60 V
- Current - Average Rectified (Io)：3A
- Voltage - Forward (Vf) (Max) @ If：650 mV @ 3 A
- Speed：Fast Recovery =< 500ns, > 200mA (Io)
- Reverse Recovery Time (trr)：-
- Current - Reverse Leakage @ Vr：200 µA @ 60 V
- Capacitance @ Vr, F：110pF @ 4V, 1MHz
- Mounting Type：Surface Mount
- Package / Case：DO-214AC, SMA Flat Leads
- Supplier Device Package：SMAF
- Operating Temperature - Junction：-55°C ~ 150°C
- Grade：-
- Qualification：-
Download product information
Overview
The B360AF-13-2477 is a surface-mount Schottky rectifier manufactured by Diodes Incorporated. It features a 60 V DC reverse voltage rating and supports an average rectified current of 3 A. The device utilizes the SMAF (DO-214AC) package configuration. Key electrical characteristics include a maximum forward voltage of 650 mV at 3 A and a reverse leakage current of 200 µA at 60 V. Junction capacitance is specified as 110 pF at 4 V and 1 MHz. The component operates within a junction temperature range of -55°C to 150°C.
Feature Summary
- Schottky barrier technology for fast recovery performance
- Surface mount construction in SMAF package
- High thermal stability across wide temperature range
Applications
- General purpose rectification
- Power supply output stages
- DC-DC converter freewheeling diodes
Procurement Notes
Verify part status carefully as this specific suffix variant may be obsolete. Confirm availability through authorized distributors or check for manufacturer-recommended substitutes like the standard B360AF-13 series. Ensure datasheet specifications match design requirements before procurement, as legacy variants often have limited production runs.
Selection Notes
Select this component for applications requiring low forward voltage drop and high surge current handling in compact surface-mount designs. The SMAF package offers space efficiency compared to larger DO-214AC variants while maintaining similar electrical ratings. Consider thermal management requirements given the 150°C junction limit.
Part Context
This part belongs to the B360 series of Schottky rectifiers from Diodes Incorporated. The series provides robust performance for general-purpose rectification tasks. The specific -2477 suffix denotes a particular manufacturing lot or packaging variation that may differ from standard commercial reels.
Replacement Considerations
Diodes Incorporated recommends the B360AF-13 as a direct substitute. Verify pinout compatibility and electrical parameters against the original design specifications before implementation.
