Product Detailed Parameters
- Description：LED RGB 0606 SMD
- Series：-
- Mfr：Harvatek Corporation
- Package：Tape & Reel (TR),Cut Tape (CT)
- Color：Red, Green, Blue (RGB)
- Configuration：Common Anode
- Lens Color：-
- Lens Transparency：-
- Millicandela Rating：630mcd Red, 630mcd Green, 630mcd Blue
- Lens Style：Rectangle with Flat Top
- Lens Size：1.60mm x 1.10mm
- Voltage - Forward (Vf) (Typ)：2V Red, 3V Green, 3V Blue
- Current - Test：10mA Red, 10mA Green, 10mA Blue
- Viewing Angle：-
- Mounting Type：Surface Mount
- Wavelength - Dominant：-
- Wavelength - Peak：-
- Features：-
- Package / Case：0606 (1616 Metric)
- Supplier Device Package：606
- Size / Dimension：1.60mm L x 1.60mm W
- Height (Max)：0.50mm
- Grade：-
- Qualification：-
Download product information
Overview
The B38G3RGB-10D0003H2U1930 is a surface-mount tri-color LED from Harvatek Corporation, housed in a 0606 (1616 metric) package measuring 1.60mm x 1.60mm with a maximum height of 0.50mm. It integrates red, green, and blue chips within a single diffused lens to produce mixed white light. The component operates at a typical forward voltage of 2V for the red channel, while the green and blue channels require 3V each. Designed for discrete indicator applications, it features a rectangular lens with a flat top and offers a viewing angle of 125 degrees.
Feature Summary
- Integrates red, green, and blue semiconductor chips into a single compact surface-mount package
- Utilizes a diffused lens design to create mixed white light output
- Features a rectangular lens shape with a flat top profile
- Supports independent color control for multi-color indicator functions
Applications
- Status indication on electronic circuit boards
- Multi-color signaling in consumer electronics devices
- Visual feedback components in industrial control panels
- Indicator lights for portable battery-powered equipment
Procurement Notes
Verify the specific ordering suffix against the manufacturer's official datasheet to ensure correct binning and optical characteristics. Confirm that the required forward voltage levels for the green and blue channels align with the system power supply design. Check RoHS compliance status and moisture sensitivity level requirements before storage and reflow soldering processes.
Selection Notes
Select this component when a compact 0606 footprint is required for tri-color or mixed white light indication. Ensure the application can accommodate the distinct forward voltage differences between the red (2V) and green/blue (3V) channels. Verify that the 125-degree viewing angle meets the visibility requirements for the intended enclosure design.
Part Context
This part belongs to Harvatek Corporation's discrete LED indicator series, designed for surface-mount technology assembly. It serves as a compact alternative to multiple single-color LEDs, reducing board space usage. The 0606 package size balances visual intensity with minimal PCB real estate consumption.
Replacement Considerations
Consider the B38G3RGB-20D0010H2U1930 as a potential variant within the same product family. Verify mechanical dimensions and electrical parameters before substitution.
