Product Detailed Parameters
- Description：0.95(L) X 0.95(W) X 0.40(H) MM
- Series：-
- Mfr：Harvatek Corporation
- Package：Tape & Reel (TR),Cut Tape (CT)
- Color：Red, Green, Blue, White (RGBW)
- Configuration：Common Anode
- Lens Color：Tinted
- Lens Transparency：Diffused
- Millicandela Rating：115mcd Red, 280mcd Green, 64mcd Blue, 330mcd White
- Lens Style：Square with Flat Top
- Lens Size：1.00mm
- Voltage - Forward (Vf) (Typ)：2.1V Red, 2.6V Green, 2.8V Blue, 2.9V White
- Current - Test：5mA Red, 5mA Green, 5mA Blue, 5mA White
- Viewing Angle：120°
- Mounting Type：Surface Mount
- Wavelength - Dominant：622nm Red, 524nm Green, 465nm Blue
- Wavelength - Peak：-
- Features：-
- Package / Case：0404 (1010 Metric)
- Supplier Device Package：404
- Size / Dimension：1.00mm L x 1.00mm W
- Height (Max)：0.50mm
- Grade：-
- Qualification：-
Download product information
Overview
The B3R14RBGW05DX001A4U1930 is an active RGBW LED indicator manufactured by Harvatek Corporation. It features a common anode configuration with red, green, blue, and white color outputs. The component utilizes a 4-SMD, no-lead package measuring 0.95mm in length, 0.95mm in width, and 0.40mm in maximum height. Electrical characteristics include forward voltages of 2.1V for red, 2.6V for green, 2.6V for blue, and 3.0V for white. Peak wavelengths are specified at 622nm for red, 524nm for green, 465nm for blue, and 415nm for white.
Feature Summary
- Integrates four distinct light-emitting diodes (red, green, blue, and white) within a single compact surface-mount package to enable complex color mixing and white balance capabilities.
Applications
- Status indication in consumer electronics
- Decorative lighting modules
- Backlighting systems requiring white spectrum support
Procurement Notes
Verify the specific ordering suffix against the manufacturer's current datasheet to ensure compatibility with required voltage and wavelength tolerances. Confirm that the common anode configuration aligns with the target circuit design before procurement. Check for RoHS compliance status and moisture sensitivity level requirements during storage and handling preparation.
Selection Notes
Select this component when space constraints require a small footprint combined with multi-color output including a dedicated white channel. Ensure the driving circuitry supports the common anode topology and can handle the cumulative current requirements of all four channels simultaneously without exceeding thermal limits.
Part Context
This part belongs to Harvatek Corporation's discrete LED indicator series, designed for applications demanding high brightness and precise color rendering in minimal board areas. It complements other RGB and RGBW offerings from the manufacturer, providing a standardized solution for integrated lighting control.
Replacement Considerations
No public confirmed substitute part numbers are available in the provided documentation. Evaluate alternative RGBW LEDs based on package dimensions, pinout configuration, and electrical specifications if substitution is necessary.
FAQ
What is the lens color of the B3R14RBGW05DX001A4U1930?
The lens color is tinted.
Does this LED use a common cathode or common anode configuration?
It uses a common anode configuration.
