B78476A8252A003

$4.65

Description：PULSE XFMR 1CT:1CT 350UH
Series：-
Mfr：EPCOS - TDK Electronics
Package：Tape & Reel (TR),Cut Tape (CT)

SKU:963b36cff0a1 Category: Pulse Transformers Brand: EPCOS - TDK Electronics

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：PULSE XFMR 1CT:1CT 350UH
Series：-
Mfr：EPCOS - TDK Electronics
Package：Tape & Reel (TR),Cut Tape (CT)
Transformer Type：LAN 10/100/1000 Base-T
Inductance：350µH
ET (Volt-Time)：-
Turns Ratio - Primary:Secondary：1CT:1CT
Mounting Type：Surface Mount
Size / Dimension：1.090" L x 0.287" W (27.69mm x 7.29mm)
Height - Seated (Max)：0.341" (8.66mm)
Operating Temperature：-40°C ~ 85°C
Grade：-
Qualification：-

Download product information

B78476A8252A003

Overview

The B78476A8252A003 is a surface-mount LAN magnetics module manufactured by TDK Electronics. It features an inductance of 350 µH and a turns ratio of 1CT:1CT. The component supports 10/100 Base-T applications and operates within a temperature range of -40°C to +85°C. Its physical dimensions are 27.69mm in length, 7.29mm in width, and a maximum seated height of 8.66mm.
