B82504WA16

Description：CMC 120UH 16A 2LN CHASSIS MOUNT
Series：B82504
Mfr：EPCOS - TDK Electronics
Package：Tray

SKU:7dce2c96e250 Category: Common Mode Chokes Brand: EPCOS - TDK Electronics

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：CMC 120UH 16A 2LN CHASSIS MOUNT
Series：B82504
Mfr：EPCOS - TDK Electronics
Package：Tray
Filter Type：Power Line
Number of Lines：2
Current Rating (Max)：16A
DC Resistance (DCR) (Max)：19mOhm (Typ)
Voltage Rating - DC：600V
Voltage Rating - AC：500V
Operating Temperature：-
Ratings：-
Approval Agency：-
Features：-
Mounting Type：Chassis Mount
Size / Dimension：3.071" L x 1.102" W (78.00mm x 28.00mm)
Height (Max)：1.457" (37.00mm)
Package / Case：-
Inductance @ Frequency：120 µH @ 100 kHz
Impedance @ Frequency：-

Download product information

B82504WA16

Overview

The B82504WA16 is a power line choke belonging to the I core choke series manufactured by EPCOS (TDK). It is designed for AC power line filtering applications with a rated voltage of 500 V AC and 600 V DC. The component features an inductance value within the range of 0.065 mH to 27 mH and supports rated currents from 1 A to 25 A, depending on the specific variant configuration. It utilizes a rectangular plastic case construction with resin potting for durability. The device operates within a temperature range of -40°C to +125°C and is intended for chassis mounting.

Feature Summary

I core choke construction providing high magnetic efficiency
Rectangular plastic case with resin potting for mechanical stability
Designed for power line filtering in industrial environments
Supports chassis mounting for secure installation

Applications

Industrial machinery power supply filtering
AC power line noise suppression
Electromagnetic compatibility (EMC) improvement in electronic equipment

Procurement Notes

Verify the exact inductance and current rating required for your application against the specific suffix codes available in the B82504W series datasheet. Confirm that the chassis mounting dimensions and terminal types match your enclosure design. Ensure the operating temperature range meets your system's environmental requirements. Cross-reference the part number with official TDK-EPCOS documentation to confirm availability and compliance status.

Selection Notes

Select this component based on the required inductance and current handling capabilities within the B82504W series specifications. Consider the physical size constraints for chassis mounting and the thermal environment where the choke will operate. Evaluate the DC resistance impact on your power line efficiency. Ensure the rated voltage exceeds the maximum system voltage including transients.

Part Context

The B82504WA16 is part of the broader B82504W series of I core chokes produced by EPCOS, now a subsidiary of TDK Electronics. This series is widely used in industrial automation and power electronics for common mode noise suppression. The components are characterized by their robust construction and ability to handle significant current loads while maintaining effective filtering performance across a wide frequency range.
