B82614R2801A030

$1.61

Description：CMC 3MH 800MA 2LN TH
Series：B82614
Mfr：EPCOS - TDK Electronics
Package：Tray

SKU:c17466cc43a4 Category: Common Mode Chokes Brand: EPCOS - TDK Electronics

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：CMC 3MH 800MA 2LN TH
Series：B82614
Mfr：EPCOS - TDK Electronics
Package：Tray
Filter Type：Power Line
Number of Lines：2
Current Rating (Max)：800mA
DC Resistance (DCR) (Max)：1.9Ohm (Typ)
Voltage Rating - DC：-
Voltage Rating - AC：250V
Operating Temperature：-
Ratings：-
Approval Agency：-
Features：-
Mounting Type：Through Hole
Size / Dimension：1.280" L x 0.827" W (32.50mm x 21.00mm)
Height (Max)：1.220" (31.00mm)
Package / Case：Vertical, 4 PC Pin
Inductance @ Frequency：3 mH @ 10 kHz
Impedance @ Frequency：-

Download product information

B82614R2801A030

Overview

The B82614R2801A030 is a power line choke and sine-wave choke manufactured by EPCOS - TDK Electronics. It features a ferrite core with a rectangular construction and operates within a temperature range of -40 °C to 125 °C. The component has a nominal inductance of 3000 µH (3 mH) at 10 kHz, a typical DC resistance of 1.9 Ω, and a current rating of 800 mA. It utilizes a vertical through-hole package with four pins, measuring 32.5 mm in length, 21 mm in width, and 31 mm in height.

Feature Summary

Designed for power line applications as a sine-wave choke
Utilizes a ferrite core for magnetic performance
Constructed in a rectangular form factor for PCB mounting

Applications

Power line filtering
Sine-wave output filter circuits
EMI suppression in electronic equipment

Procurement Notes

Verify the specific datasheet version from TDK Electronics or authorized distributors to confirm RoHS compliance status and exact mechanical dimensions. Ensure the selected variant matches the required lead length and pin configuration for your PCB layout. Cross-reference the part number B82614R2801A030 with official manufacturer documentation to validate electrical parameters such as inductance tolerance and thermal ratings before integration.

Selection Notes

Select this component when a common mode choke with 3 mH inductance and 800 mA current handling is required for power line applications. Consider the 1.9 Ω DC resistance impact on voltage drop and the 31 mm height constraint for enclosure design. Verify compatibility with operating temperatures up to 125 °C and ensure the through-hole mounting style fits the assembly process.

Part Context

This component belongs to the B82614 series of power line chokes produced by EPCOS, now part of TDK Electronics. The series is designed for general purpose inductor applications requiring effective electromagnetic interference suppression. The B82614R2801A030 specifically denotes a variant with defined inductance and current characteristics suitable for AC power input stages.

Replacement Considerations

Consult official TDK Electronics substitution guides for verified alternatives. Ensure any replacement maintains equivalent inductance, current rating, and physical footprint.
