B82625B2302M001

Overview

The B82625B2302M001 is a ring core common mode choke from the EPCOS B82625 series, designed for power line applications. It features an iron powder core construction suitable for rated voltages of 250 V AC and 350 V DC. The component provides a rated inductance of 700 µH with a maximum current handling capacity of 3 A. It utilizes a through-hole mounting style and exhibits a maximum DC resistance of 120 mOhms. This double choke configuration is engineered for electromagnetic interference suppression in industrial and consumer electronics environments.

Feature Summary

• Ring core construction utilizing iron powder material for stable magnetic performance
• Dual-line configuration designed for effective common mode noise attenuation
• Through-hole mounting capability for robust mechanical integration

Applications

• Power supply input filtering
• Electromagnetic interference suppression in industrial equipment
• Consumer electronics power lines

Procurement Notes

Verify the specific ordering code against official TDK documentation to ensure correct inductance and current ratings. Confirm package type and lead form compatibility with assembly requirements. Cross-reference datasheet parameters for thermal limits and saturation characteristics before finalizing procurement specifications.

Selection Notes

Select this component based on required inductance values and current carrying capabilities for common mode noise reduction. Evaluate physical dimensions and mounting constraints for PCB layout integration. Ensure voltage ratings align with system operating conditions to maintain safety and reliability standards.

Part Context

This component belongs to the B82625 series of ring core chokes manufactured by EPCOS, now part of the TDK Group. The series offers various inductance options tailored for power line filtering applications. These components are widely utilized in electronic systems requiring reliable electromagnetic compatibility and noise suppression capabilities.

Replacement Considerations

Consult official TDK documentation for verified substitute part numbers within the B82625 series or compatible families. Ensure electrical parameters such as inductance, current rating, and DC resistance match original requirements when considering alternatives.
