B82724V2103U040

Overview

The B82724V2103U040 is a power line common mode choke manufactured by EPCOS, part of the TDK Electronics portfolio. This component is designed for electromagnetic interference suppression in AC power applications. It features an inductance of 3.3 mH and supports a maximum current rating of 10 A. The device operates within a temperature range of -40°C to +125°C and is rated for 250 V AC.

Feature Summary

• Provides common mode noise filtering for power lines
• Supports high current loads up to 10 A
• Rated for 250 V AC operation

Applications

• AC power line filtering
• Electromagnetic interference suppression
• Industrial electronics equipment

Procurement Notes

Verify the specific manufacturer documentation for detailed mechanical dimensions, soldering guidelines, and safety certifications. Confirm that the 3.3 mH inductance and 10 A current ratings align with your circuit requirements before procurement.

Selection Notes

Select this component when designing circuits requiring common mode chokes for AC power lines. Ensure the operating environment stays within the specified -40°C to +125°C range and that the voltage does not exceed 250 V AC.

Part Context

This component belongs to the B82724 series of ring core chokes from EPCOS/TDK. These components are widely used in industrial and consumer electronics to ensure stable power supply and protect electronic circuits from voltage spikes and electromagnetic interference.

Replacement Considerations

Public confirmed substitute part numbers are not available in the provided data.
