B82725S2333A040

Overview

The B82725S2333A040 is a surface-mount common mode choke from the B82725S series, manufactured by TDK Electronics. It utilizes a ring core construction to provide effective electromagnetic interference suppression in power line applications. The component features a rated inductance of 180µH and supports a high current capacity of 33A. Its physical dimensions are 40mm x 38mm x 20.7mm, designed for robust integration into electronic circuits requiring reliable noise filtering.

Feature Summary

• Surface-mount ring core construction for stable performance
• High current handling capability suitable for power lines
• Designed for effective common mode noise suppression

Applications

• Power line filtering
• Electromagnetic interference suppression
• Industrial electronics

Procurement Notes

Verify the manufacturer designation as TDK Electronics, noting that EPCOS is part of the TDK Group. Confirm the specific suffix A040 corresponds to the required packaging or variant. Ensure compatibility with the specified 40mm x 38mm footprint during procurement planning.

Selection Notes

Select this component for applications requiring high current handling up to 33A and significant inductance of 180µH. The surface-mount package facilitates automated assembly. Consider the physical size constraints when designing the PCB layout for adequate clearance and thermal management.

Part Context

This component belongs to the B82725S series of common mode chokes. TDK Electronics produces these components to address electromagnetic compatibility requirements in various electronic systems. The series offers standardized dimensions and electrical characteristics for consistent design implementation across different product lines.

Replacement Considerations

Consult official TDK documentation for verified substitute part numbers. Do not assume cross-compatibility with other series without verifying electrical parameters and mechanical dimensions against the original specifications.
