B82726E6263A040

$7.62

Description：CMC 600UH 26A 2LN TH
Series：B82726
Mfr：EPCOS - TDK Electronics
Package：Tray

SKU:fd59df3f7103 Category: Common Mode Chokes Brand: EPCOS - TDK Electronics

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：CMC 600UH 26A 2LN TH
Series：B82726
Mfr：EPCOS - TDK Electronics
Package：Tray
Filter Type：Power Line
Number of Lines：2
Current Rating (Max)：26A
DC Resistance (DCR) (Max)：1.7mOhm (Typ)
Voltage Rating - DC：1000V (1kV)
Voltage Rating - AC：600V
Operating Temperature：-40°C ~ 125°C
Ratings：-
Approval Agency：UR
Features：-
Mounting Type：Through Hole
Size / Dimension：1.890" Dia x 1.024" L (48.00mm x 26.00mm)
Height (Max)：1.772" (45.00mm)
Package / Case：Vertical, 4 PC Pin
Inductance @ Frequency：600 µH @ 100 kHz
Impedance @ Frequency：-

Download product information

B82726E6263A040

Overview

The B82726E6263A040 is a current-compensated ring core double choke designed for power line applications. It features a rated voltage of 250 V AC and supports rated currents ranging from 20 to 24 A. The inductance value is specified at 1.6 mH, with a maximum DC resistance of 4.5 mOhm. The component utilizes through-hole mounting and operates within a temperature range of -40°C to 125°C. Its physical dimensions are 50.00 mm in length, 23.00 mm in width, and 49.00 mm in height.

Feature Summary

Current-compensated design for symmetrical interference suppression
Insulation suitable for high voltage applications
Low stray inductance characteristics

Applications

Power line filtering
High voltage insulation environments
Symmetrical interference suppression circuits

Procurement Notes

Verify the specific suffix against official TDK/EPCOS documentation to confirm exact electrical ratings and mechanical tolerances. Ensure compatibility with required voltage classes and thermal operating ranges before integration. Cross-reference datasheet revisions to confirm material compliance and pin configuration details.

Selection Notes

Select this component when symmetrical noise reduction is critical for power line integrity. The current-compensated architecture minimizes common-mode effects while maintaining low impedance for differential signals. Verify that the 1.6 mH inductance aligns with the target frequency attenuation requirements and that the 20-24 A current rating exceeds peak load expectations.

Part Context

This device belongs to the B82726 series of current-compensated ring core double chokes manufactured by EPCOS (TDK Electronics). The series is engineered for robust performance in demanding power electronics environments, offering reliable electromagnetic interference mitigation through specialized magnetic core construction.

Replacement Considerations

Consult official substitution lists for equivalent current-compensated ring core chokes with matching inductance and current ratings. Verify dimensional compatibility for through-hole mounting before replacing.
