B82726S2163N002

$9.32

Description：CMC 1.4MH 16A 2LN TH
Series：B82726
Mfr：EPCOS - TDK Electronics
Package：Tray

SKU:575e1b094e3a Category: Common Mode Chokes Brand: EPCOS - TDK Electronics

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：CMC 1.4MH 16A 2LN TH
Series：B82726
Mfr：EPCOS - TDK Electronics
Package：Tray
Filter Type：Power Line
Number of Lines：2
Current Rating (Max)：16A
DC Resistance (DCR) (Max)：7.1mOhm (Typ)
Voltage Rating - DC：-
Voltage Rating - AC：250V
Operating Temperature：-40°C ~ 125°C
Ratings：-
Approval Agency：-
Features：-
Mounting Type：Through Hole
Size / Dimension：1.969" L x 0.906" W (50.00mm x 23.00mm)
Height (Max)：1.929" (49.00mm)
Package / Case：Vertical, 4 PC Pin
Inductance @ Frequency：1.4 mH @ 10 kHz
Impedance @ Frequency：-

Download product information

B82726S2163N002

Overview

The B82726S2163N002 is a current-compensated ring core double choke from the EPCOS (TDK) B82726S series. It features an inductance of 1.4 mH at 10 kHz and supports a maximum DC current of 16 A. The component has a typical DC resistance of 7.1 mOhm and operates within a temperature range of -40°C to +125°C. Rated for 250 V AC, it utilizes a ferrite core with vertical through-hole mounting and radial leads spaced 19.5 mm apart.
