B82786C0104H002

$0.48

Description：CMC 100UH 150MA 2LN 5.1KOHM SMD
Series：ACT1210
Mfr：EPCOS - TDK Electronics
Package：Tape & Reel (TR)

SKU:522c8eeb42a3 Category: Common Mode Chokes Brand: EPCOS - TDK Electronics

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：CMC 100UH 150MA 2LN 5.1KOHM SMD
Series：ACT1210
Mfr：EPCOS - TDK Electronics
Package：Tape & Reel (TR)
Filter Type：Signal Line
Number of Lines：2
Current Rating (Max)：150mA
DC Resistance (DCR) (Max)：1.5Ohm
Voltage Rating - DC：80V
Voltage Rating - AC：-
Operating Temperature：-55°C ~ 150°C
Ratings：AEC-Q200
Approval Agency：-
Features：-
Mounting Type：Surface Mount
Size / Dimension：0.126" L x 0.098" W (3.20mm x 2.50mm)
Height (Max)：0.098" (2.50mm)
Package / Case：Horizontal, 4 PC Pad
Inductance @ Frequency：100 µH @ 100 kHz
Impedance @ Frequency：5.1 kOhms @ 10 MHz

Download product information

B82786C0104H002

Overview

The B82786C0104H002 is a surface-mount common mode choke manufactured by EPCOS (TDK Electronics). It features an inductance of 100 µH and a rated current of 150 mA. Designed for automotive applications, it complies with the AEC-Q200 reliability standard. The component operates within an ambient temperature range of -55 °C to +150 °C and conforms to RoHS regulations.
